Honda XR600RA (88) MOTORCYCLE, JPN, VIN# JH2PE040-JK300009 TO JH2PE040-JK301886 TRANSMISSION Diagram

#

Description
Price

1

GUIDE, LIFTER ROD

15171-KN8-000

$14.89

2

MAINSHAFT, TRANSMISSION (13T)

23211-MN1-670

Unavailable

3

COUNTERSHAFT This part replaces 23220-MK2-000.

23220-MN9-641

Unavailable

3

COUNTERSHAFT This part replaces 23220-MN9-640.

23220-MN9-641

Unavailable

3

COUNTERSHAFT

23220-MN9-641

Unavailable

4

GEAR, COUNTERSHAFT LOW (31T)

23411-MN1-670

Unavailable

5

GEAR, MAINSHAFT SECOND (17T)

23421-MK2-000

Unavailable

6

BUSH (20MM)

23422-MG2-000

$23.00

7

GEAR, COUNTERSHAFT SECOND (28T)

23431-MN1-670

Unavailable

8

BUSH (25MM)

23432-MN1-670

$27.93

9

BUSH (25MM)

23432-MK2-000

$27.93

10

BUSH (25MM)

23432-MN1-670

$27.93

11

GEAR, MAINSHAFT THIRD (20T)

23441-MK2-000

Unavailable

12

GEAR, COUNTERSHAFT THIRD (25T) This part replaces 23451-MN1-670.

23451-MN9-000

$137.66

12

GEAR, COUNTERSHAFT THIRD (25T)

23451-MN9-000

$137.66

14

GEAR, MAINSHAFT FOURTH (23T) This part replaces 23461-MN1-670.

23461-MN1-671

Unavailable

14

GEAR, MAINSHAFT FOURTH (23T)

23461-MN1-671

Unavailable

15

GEAR, COUNTERSHAFT FOURTH (23T) This part replaces 23471-MN1-670.

23471-MN9-000

$180.02

16

GEAR, MAINSHAFT FIFTH (25T) | Use up to Engine SN 5302205 This part replaces 23481-MK2-000.

23481-MN1-670

Unavailable

16

GEAR, MAINSHAFT FIFTH (25T)

23481-MN1-670

Unavailable

17

BUSH, SPLINE (28MM)

23485-369-000

$29.59

18

GEAR, COUNTERSHAFT FIFTH (21T) This part replaces 23491-MN1-670.

23491-MN9-000

$154.59

18

GEAR, COUNTERSHAFT FIFTH (21T)

23491-MN9-000

$154.59

19

PLATE, BEARING SETTING

23531-MG2-790

$4.46

20

SPROCKET, DRIVE (14T) This part replaces 23801-MK2-000.

23801-MK2-010

Unavailable

20

SPROCKET, DRIVE (14T)

23801-MK2-010

Unavailable

22

PLATE, DRIVE SPROCKET FIXING

23811-292-000

$2.51

23

GEAR, KICK STARTER IDLE (33T)

28221-MN1-670

Unavailable

24

BUSH (16MM)

28222-MG3-000

Unavailable

25

BOLT, FLANGE SOCKET (6X14)

90071-MF5-000

$3.35

26

BOLT, FLANGE (6X12)

90118-958-003

$3.24

27

WASHER, THRUST (25MM)

90412-ZE5-000

$4.71

28

PLATE, THRUST (20MM)

90451-MG3-000

$4.13

29

WASHER, THRUST (25MM)

90451-413-000

$3.26

30

CIRCLIP (25MM)

90601-107-000

$3.74

31

BEARING, RADIAL BALL (6305)

91002-MG2-790

Unavailable

31

BEARING, RADIAL BALL (6305) (TOYO)

91002-MG2-791

$41.07

32

BEARING, RADIAL BALL (5205A)

91002-422-008

$68.41

33

BEARING, RADIAL BALL (6204U) This part replaces 91003-MK2-680.

96140-62040-10

$21.84

33

BEARING, RADIAL BALL (6204U)

96140-62040-10

$21.84

34

BEARING, NEEDLE (20MM)

91022-MG2-791

$46.80

35

OIL SEAL (25X45X7) (ARAI)

91204-MG3-003

$9.80

36

OIL SEAL (20X35X5.5) (ARAI)

91204-216-003

$6.31
