Honda XR250RA (82) MOTORCYCLE, JPN, VIN# JH2ME010-CM300008 FRONT BALANCER Diagram

#

Description
Price

1

GEAR, BALANCER DRIVEN (NOT AVAILABLE)

13410-473-000

Unavailable

3

HOLDER, BALANCER SHAFT

13412-KA6-000

Unavailable

4

FLANGE, BALANCER HOLDER (NOT AVAILABLE)

13413-KA6-000

Unavailable

6

WEIGHT, FR. BALANCER

13421-KA6-000

Unavailable

7

WASHER, SPECIAL (22X8.5X2) (NOT AVAILABLE)

90436-611-000

Unavailable

9

WASHER (20MM) (NOT AVAILABLE)

90456-473-000

Unavailable

10

WASHER, THRUST (20MM)

90458-292-000

$3.54

11

SET-RING (20MM)

90605-200-000

$2.92

13

BEARING, NEEDLE (20X26X20)

91011-P48-008

Unavailable

13

BEARING, NEEDLE (20X26X20) This part replaces 91011-428-008.

91011-P48-008

Unavailable

13

BEARING, NEEDLE (20X26X20) This part replaces 91011-473-000.

91011-P48-008

Unavailable

15

BEARING, NEEDLE (20X26X17) (TOYO) | Use up to Engine SN 5306428 This part replaces 91012-428-008.

91012-471-008

Unavailable

15

BEARING, NEEDLE (20X26X17) (TOYO)

91012-471-008

Unavailable

15

BEARING, NEEDLE (20X26X17) (TOYO) | Use up to Engine SN 5306428 This part replaces 91012-473-000.

91012-471-008

Unavailable

16

CIRCLIP (OUTER) (20MM)

94510-20000

$1.49

17

CIRCLIP (OUTER) (38MM)

94510-38000

$2.28

18

BOLT, FLANGE (8X20) This part replaces 95700-08020-00.

95701-08020-00

$1.78

18

BOLT, FLANGE (8X20)

95701-08020-00

$1.78
