Polaris XPEDITION 425 - A02CK42AA/AB INTAKE and EXHAUST - A02CK42AA/AB (4970327032C10) Diagram

#

Description
Price

1

PLUG

3084845

Unavailable

2

Gasket, Plug

3084920

Unavailable

3

Spring, Tensioner

3086839

Unavailable

4

Asm., Tensioner [Incl. 1-3]

3086813

Unavailable

5

Gasket, Tensioner

3084922

Unavailable

6

Asm., Intake Rocker Arm [Incl. 8,9]

3084910

$125.46

6

Asm., Intake Rocker Arm [Incl. 8,9]

3084910

$125.46

7

Asm., Exhaust Rocker Arm [Incl. 8,9]

3084913

$166.24

8

Nut

3084912

$3.97

8

Nut

3084912

$3.97

8

Nut

3084912

$3.97

9

Screw, Adjusting

3084911

$9.52

9

Screw, Adjusting

3084911

$9.52

9

Screw, Adjusting

3084911

$9.52

10

SHAFT, ROCKER

3084909

$52.60

11

COLLET, VALVE

3084908

$4.84

11

COLLET, VALVE

3084908

$4.84

12

Retainer, Spring

3086893

Unavailable

12

Retainer, Spring

3086893

Unavailable

13

Spring, Valve

3084906

$28.32

13

Spring, Valve

3084906

$28.32

14

Camshaft [Incl. 15-18]

3086212

$379.99

15

PIN, DOWEL

3086838

$7.14

16

LEVER, RELEASE

3085348

Unavailable

17

SPRING, RETURN

3085076

Unavailable

18

PIN, DOWEL

3084899

$7.14

19

SPROCKET 2

3084914

Unavailable

20

Bolt and Washer

3081657

$4.76

21

GUIDE, CHAIN

3084916

Unavailable

22

CHAIN, TIMING

3084915

$101.17

23

Bolt, Pivot, Lever

3084924

Unavailable

24

LEVER

3084917

Unavailable

25

VALVE, INTAKE

3085349

$68.79

26

VALVE, EXHAUST

3085412

$93.08

27

BOLT, FLANGE

3084874

Unavailable
