Polaris XPEDITION 425 - A02CK42AA/AB CLUTCH - A02CK42AA/AB (4970327032D08) Diagram

#

Description
Price

1

Key

3086330

Unavailable

2

Shaft, Output

3086324

$287.99

3

Seal, Oil

3086327

Unavailable

4

Spring, Reverse Arm

3086306

Unavailable

5

Asm., Reverse Arm

3086919

$91.19

6

Bevel and Gear Set [Incl. 2,3,6,7,9,12]

3086507

Unavailable

7

Ring, Snap

3086328

$14.23

8

Bearing, Ball

3086329

$96.79

9

Nut, Lock

3086326

$31.99

10

O-Ring

3086331

$6.63

11

Shim [.15]

3086289

$2.63

11

Shim [.2]

3086290

$2.63

11

Shim [.25]

3086291

$2.78

11

Shim [.3]

3086292

$2.46

11

Shim [.5]

3086293

$2.47

11

Shim [.175]

3086294

$2.47

11

Shim [.225]

3086295

$2.47

11

Shim [.275]

3086296

$2.47

12

Holder, Bearing

3086325

$148.79

13

Bolt, Flange

3086332

$1.83

14

Asm., Reverse Cam

3086917

Unavailable

15

Switch, Position

3086920

Unavailable

16

Bolt, Flange

3084566

$3.19

17

Washer, Lock

3086314

$4.23

18

Nut, Lock

3086310

$6.23

19

Chain

3086304

Unavailable

20

Sprocket, Driven

3086303

$78.39

21

Bearing, Ball

3086321

Unavailable

22

Asm., Pinion and Shaft [Incl. 1-3,6-10,12,21,22]

3086318

Unavailable

23

Washer

3086380

Unavailable

24

Gear, Primary

3086506

Unavailable

25

Arm, Stopper

3086302

$18.23

26

Bolt

3086311

$12.39

27

Arm, Release

3086301

Unavailable

28

Spacer

3086317

$12.70

29

Spacer

3086316

Unavailable

30

Spring, Return

3086307

Unavailable

31

Spring, Stopper Arm

3086308

$9.91

32

Key, Woodruff

3086312

Unavailable

33

Asm., Shift Shaft

3086298

Unavailable

34

Spring, Shift

3086309

Unavailable

34

Spring, Shift

3086309

Unavailable

35

Spacer

3086315

Unavailable
