Polaris XPEDITION 325 - A02CK32AA INTAKE and EXHAUST - A02CK32AA (4970287028C11) Diagram

#

Description
Price

1

Screw, Adjusting

3084911

$9.52

1

Screw, Adjusting

3084911

$9.52

2

Nut

3084912

$3.97

2

Nut

3084912

$3.97

3

Asm., Rocker Arm [Incl. 1,2]

3084910

$125.46

4

Shaft, Rocker

3086442

$38.89

5

Washer, Wave

3085836

$5.56

6

COLLET, VALVE

3084908

$4.84

6

COLLET, VALVE

3084908

$4.84

7

Retainer, Spring

3086893

Unavailable

7

Retainer, Spring

3086893

Unavailable

8

SPRING, VALVE

3086892

$28.32

8

SPRING, VALVE

3086892

$28.32

9

Lever, Release

3086439

$86.11

10

Spring, Return

3086804

Unavailable

11

Camshaft [Incl. 9,10,12]

3086803

$489.99

12

PIN, DOWEL

3084899

$7.14

13

Valve, Intake

3085778

Unavailable

14

Valve, Exhaust

3086441

$56.65

15

Guide, Chain

3086445

$40.46

16

Chain, Timing

3086444

Unavailable

17

GASKET, TENSIONER

3086448

$6.46

18

Tensioner

3086493

Unavailable

19

BOLT, FLANGE

3083361

Unavailable

20

PIN

3087132

$10.32

21

Spring

3087131

Unavailable

22

PLUG

3087129

Unavailable

23

Gasket

3087130

$11.32

24

Sprocket 2

3086443

Unavailable

25

Washer

3083663

Unavailable

26

BOLT, FLANGE

3086449

$7.14

27

Lever

3086446

$80.94

28

Bolt, Pivot

3084924

Unavailable
