Polaris XPEDITION 325 - A00CK32AA CLUTCH - A00CK32AA (4954895489D009) Diagram

#

Description
Price

1

SHAFT-SHIFT FORK

3086375

$11.99

1

SHAFT-SHIFT FORK

3086375

$11.99

2

FORK,SHIFT,DRIVEN

3086377

Unavailable

3

BOLT,LOCK

3086370

$3.19

4

Washer

3086369

Unavailable

5

CAM,SHIFT

3086368

Unavailable

6

BEARING-BALL

3086373

$22.39

7

Pin

3086371

Unavailable

8

SHIFT DRUM,ASM (Incl. 3-8,21)

3086938

$198.39

8

DRUM,SHIFT

3086939

$181.59

9

PIN,DOWEL

3086379

$1.98

10

FORK,SHIFT DRIVE

3086376

$78.39

11

BEARING-BALL

3086348

$22.39

12

Washer

3086350

$1.49

13

GEAR(2ND DRIVE)

3086928

$62.39

14

Collar

3086345

$6.23

15

GEAR(5TH DRIVE)

3086931

$90.39

16

Washer

3086346

$5.43

16

Washer

3086346

$5.43

17

RING,SNAP

3086349

$1.83

17

RING,SNAP

3086349

$1.83

18

GEAR(4TH DRIVE)

3086930

$116.79

19

GEAR(3RD DRIVE)

3086929

$79.99

20

MAIN SHAFT,ASM (Incl. 11-20,22)

3086926

$288.81

20

SHAFT,MAIN

3086927

$179.19

21

Pin

3086372

Unavailable

22

BEARING-BALL

3086347

$28.79

22

BEARING-BALL

3086347

$28.79

23

BUSH,FLANGE

3086382

$19.19

24

Washer

3086313

$6.23

25

WASHER-LOCK

3086286

Unavailable

26

NUT,LOCK

3086285

Unavailable

27

Gear

3086937

$148.79

28

GEAR(3RD DRIVEN)

3086934

$128.79

29

RING,SNAP

3086363

$2.23

29

RING,SNAP

3086363

$2.23

29

RING,SNAP

3086363

$2.23

30

Washer

3086359

$3.99

30

Washer

3086359

$3.99

31

GEAR(4TH DRIVEN)

3086935

$86.39

32

GEAR(5TH DRIVEN)

3086936

$91.99

33

GEAR(2ND DRIVEN)

3086933

$135.35

33

GEAR(2ND DRIVEN)

3086933

$135.35

34

Clutch

3086357

$150.39

35

Washer

3086364

$9.59

36

Spacer

3086941

$4.07

37

SPROCKET-DRIVE

3086374

$67.19

38

Washer

3231513

$4.39

39

SHAFT-COUNTER

3086352

$179.99

39

COUNTER SHAFT,ASM (Incl. 22,27-35,38-41)

3086932

Unavailable

40

BEARING-BALL

3086362

$27.99

41

Plug

3086365

$9.11

42

Pin

3086337

$6.23

43

Pin

3086338

Unavailable

44

Gear

3086925

$110.39

45

Collar

3086336

$24.39

46

SHAFT-REVERSE

3086334

$25.98

46

REVERSE SHAFT,ASM (Incl. 42-46)

3086924

$134.39
