Polaris XPEDITION 325 - A00CK32AA CLUTCH - A00CK32AA (4954895489D008) Diagram

#

Description
Price

1

Key

3086330

Unavailable

2

SHAFT-OUTPUT

3086324

$287.99

3

SEAL,OIL

3086327

Unavailable

4

SPRING-REVERSE ARM

3086306

Unavailable

5

REVERSE ARM,ASM

3086919

Unavailable

6

OUTPUT SHAFT,ASM. Substituted by 3086318 (Incl. 2,3,6,7,9,12)

3086322

Unavailable

6

Bevel and Gear Set

3086507

Unavailable

7

RING,SNAP

3086328

Unavailable

8

BEARING-BALL

3086329

$96.03

9

NUT,LOCK

3086326

Unavailable

10

O-Ring

3086331

$6.59

11

SHIM (.15)

3086289

Unavailable

11

SHIM (.2)

3086290

$2.62

11

SHIM (.25)

3086291

$2.78

11

SHIM (.3)

3086292

$2.46

11

SHIM (.5)

3086293

Unavailable

11

SHIM (.175)

3086294

Unavailable

11

SHIM (.225)

3086295

$2.46

11

SHIM (.275)

3086296

Unavailable

12

HOLDER,BEARING

3086923

Unavailable

13

BOLT,FLANGE

3086332

$1.83

14

REVERSE CAM,ASM

3086917

Unavailable

15

SWITCH,POSITION

3086920

Unavailable

16

BOLT, FLANGE(10)

3084566

$3.17

17

WASHER-LOCK

3086314

Unavailable

18

NUT,LOCK

3086310

$6.19

19

Chain

3086304

Unavailable

20

SPROCKET-DRIVEN

3086303

$77.78

21

BEARING-BALL

3086321

Unavailable

22

PINION,DRIVE ASM. Substituted by 3086318 (Incl. 28,29)

3086319

Unavailable

22

PINION-DRIVE Substituted by 3086507

3086320

Unavailable

22

PINION AND SHAFT,ASM Substituted by 3086318 (Incl. 1-3,6-10,12,21,22)

3086922

Unavailable

23

Washer

3086380

Unavailable

24

GEAR,PRIMARY

3086918

$165.87

25

ARM,STOPPER

3086302

$18.10

26

BOLT,STOPPER ARM

3086311

$12.30

27

ARM,RELEASE

3086301

Unavailable

28

Spacer

3086317

$12.70

29

Spacer

3086316

Unavailable

30

SPRING-RETURN

3086307

Unavailable

31

SPRING-STOPPER ARM

3086308

$9.84

32

KEY,WOODRUFF

3086312

Unavailable

33

SHIFT SHAFT,ASM.

3086298

Unavailable

34

SPRING-SHIFT

3086309

Unavailable

34

SPRING-SHIFT

3086309

Unavailable

35

Spacer

3086315

Unavailable
