Yamaha XL700Y (XL700) F0M5 2000 OIL TANK Diagram
#
Description
Price
1
. ROLL OVER VALVE
FJ0-67766-00-00
Unavailable
3
CLAMP
90464-32801-00
Unavailable
4
RIVET, BLIND
90267-48802-00
Unavailable
5
HOSE, AIR VENT 3
GJ3-U7856-20-00
Unavailable
6
CLAMP
90465-10098-00
Unavailable
7
MAT 3
GH1-U759D-00-00
Unavailable
8
TANK, OIL
GJ3-U775B-02-00
Unavailable
9
PACKING, OIL CAP
GJ3-U778C-00-00
Unavailable
10
PACKING, OIL FILLER
GJ3-U778E-00-00
Unavailable
11
CAP, OIL FILLER
GJ3-U778B-00-00
Unavailable
12
SOCKET, OIL FILLER
GJ3-U778D-00-00
Unavailable
13
CHAIN BALL
EU0-U7835-00-00
Unavailable
14
SCREW,TAPPING (EU0)
97780-40110-00
Unavailable
15
. RIVET, BLIND
90267-40935-00
Unavailable
16
SCREW, FLAT HEAD TAPPING
FX1-67869-00-00
Unavailable
17
HOSE, OIL FILLER
GU2-U776C-00-00
Unavailable
18
BAND, HOSE 52
90601-152U3-00
Unavailable
19
STRAINER, OIL
6J8-13411-00-00
Unavailable
20
GASKET, STRAINER COVER
6J8-13414-00-00
Unavailable
