Honda XL350K1A MOTORCYCLE, JPN, VIN# XL350-2000001 TO XL350-2016790 SPEEDOMETER + TACHOMETER Diagram

#

Description
Price

1

RUBBER, AIR CLEANER HOUSING SETTING

17245-107-010

$2.89

2

RUBBER, REGULATOR CUSHION This part replaces 31403-300-000.

31403-323-000

$3.38

2

RUBBER, REGULATOR CUSHION

31403-323-000

$3.38

3

HEADLIGHT ASSY. (6V 35/25W) (NOT AVAILABLE)

33100-329-671

Unavailable

4

RIM, HEADLIGHT (NOT AVAILABLE)

33101-329-671

Unavailable

5

SCREW, HEADLIGHT BEAM ADJUSTING

33103-329-003

Unavailable

5

SCREW, HEADLIGHT BEAM ADJUSTING This part replaces 33103-329-671.

33103-329-003

Unavailable

6

SPRING, HEADLIGHT BEAM ADJUSTING (NOT AVAILABLE)

33107-283-000

Unavailable

7

NUT, HEADLIGHT BEAM ADJ.

33117-001-023

$2.39

7

NUT, HEADLIGHT BEAM ADJ. This part replaces 33117-292-003.

33117-001-023

$2.39

8

HEADLIGHT UNIT

33120-329-671

Unavailable

9

SCREW, UNIT HOLDER (NOT AVAILABLE)

33125-329-003

Unavailable

10

NUT, UNIT HOLDER

33128-200-033

Unavailable

11

BULB, DASH (6V3W) (STANLEY)

34902-202-000

$3.08

12

BULB, SPEEDOMETER (6V1.7W1CP) (51) (STANLEY)

34908-230-000

$4.67

13

RESISTOR (NOT AVAILABLE)

35400-329-671

Unavailable

14

STAY, RESISTOR (NOT AVAILABLE)

35403-356-670

Unavailable

15

COLLAR, STARTER MAGNETIC SWITCH SETTING (NOT AVAILABLE)

35851-292-000

Unavailable

16

RING, R. METER SETTING

37111-453-008

Unavailable

17

RING, L. METER SETTING

37112-453-008

Unavailable

18

RUBBER, METER (NOT AVAILABLE)

37113-453-008

Unavailable

19

PLATE, METER SET

37211-356-000

Unavailable

20

SPEEDOMETER ASSY. (MPH) | Use up to Frame SN 2000513

37230-356-700

Unavailable

20

SPEEDOMETER ASSY. (MPH) | Use from Frame SN 2000514

37230-356-701

Unavailable

21

TACHOMETER ASSY. (NOT AVAILABLE)

37240-356-700

Unavailable

22

COLLAR, INSTRUMENT SETTING

37243-453-000

Unavailable

23

RUBBER, METER SETTING

37244-307-670

$2.67

24

CABLE ASSY., TACHOMETER (NOT AVAILABLE)

37260-356-000

Unavailable

25

LIGHT ASSY., BEAM PILOT (IMASEN) This part replaces 37550-329-005.

37550-329-015

Unavailable

25

LIGHT ASSY., BEAM PILOT (IMASEN)

37550-329-015

Unavailable

26

LENS, BEAM PILOT (IMASEN) (NOT AVAILABLE) This part replaces 37551-329-005.

37551-329-015

Unavailable

26

LENS, BEAM PILOT (IMASEN) (NOT AVAILABLE)

37551-329-015

Unavailable

27

LABEL, BEAM PILOT LAMP

37555-370-740

Unavailable

28

HORN ASSY. (MITSUBA) (NOT AVAILABLE)

38100-329-014

Unavailable

29

CABLE ASSY., SPEEDOMETER This part replaces 44830-MA1-730.

44830-426-830

$25.47

29

CABLE ASSY., SPEEDOMETER This part replaces 44830-356-000.

44830-426-830

$25.47

29

CABLE ASSY., SPEEDOMETER

44830-426-830

$25.47

30

CASE, HEADLIGHT *NH42MC* (CUSTOM SILVER) (NOT AVAILABLE)

61301-336-000NQ

Unavailable

31

COLLAR, HEADLIGHT CASE

61302-292-000

Unavailable

32

WASHER, HEADLIGHT CASE

61303-336-000

Unavailable

33

COLLAR, HEADLIGHT SETTING

61304-292-000

$3.47

34

GROMMET, HEADLIGHT CASE (NOT AVAILABLE)

61304-336-003

Unavailable

35

STAY ASSY., HEADLIGHT *NH83L* (OFF BLACK) (NOT AVAILABLE)

61313-329-020CT

Unavailable

36

RUBBER, HEADLIGHT STAY (NOT AVAILABLE)

61316-329-010

Unavailable

37

STAY A, HEADLIGHT (LOWER) (NOT AVAILABLE)

61317-329-020

Unavailable

38

STAY B, HEADLIGHT (LOWER) (NOT AVAILABLE)

61318-329-010

Unavailable

39

COLLAR C, MOUNTING

80109-329-000

Unavailable

40

BOLT, FLANGE (10X25)

90124-369-000

Unavailable

41

BOLT, METER SETTING

90159-356-000

$4.58

42

NUT (6X15)

90282-329-000

$4.67

43

WASHER B, HANDLE HOLDER SETTING

90525-030-000

$1.75

44

WASHER (6.5X20)

90545-292-000

$1.77

46

BOLT, HEX. (6X20) This part replaces 92000-06020.

92101-06020-0A

$1.49

46

BOLT, HEX. (6X20)

92101-06020-0A

$1.49

48

SCREW, PAN (5X16)

93500-05016-0B

$1.49

49

SCREW, PAN (5X55)

93500-05055-0A

$1.20

50

SCREW, OVAL (6X22) This part replaces 93700-06022.

93700-06022-0A

Unavailable

50

SCREW, OVAL (6X22)

93700-06022-0A

Unavailable

51

NUT, CAP (6MM) This part replaces 94021-06000.

94021-06020

$1.73

51

NUT, CAP (6MM) This part replaces 94021-06000-0S.

94021-06020

$1.73

51

NUT, CAP (6MM)

94021-06020

$1.73

51

NUT, CAP (6MM) This part replaces 94021-06020-0S.

94021-06020

$1.73

51

NUT, CAP (6MM) This part replaces 94022-06020.

94021-06020

$1.73

52

NUT, CAP (8MM)

94021-08070-0S

$1.55

53

WASHER, PLAIN (4MM)

94101-04000

$1.49

55

WASHER, PLAIN (8MM)

94101-08000

$1.49

57

WASHER, SPRING (5MM)

94111-05000

$1.49

59

WASHER, SPRING (8MM)

94111-08000

$1.49

61

PIN, LOCK (5MM)

94251-05000

$1.49

62

BOLT, FLANGE (6X12) This part replaces 95700-06012-00.

95701-06012-00

$1.62

62

BOLT, FLANGE (6X12)

95701-06012-00

$1.62
