1993 Yamaha WRB650RA Steering 2 Diagram

← All diagrams

Find the part on the Steering 2 diagram for your 1993 Yamaha WRB650RA, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1993 Yamaha WRB650RA Steering 2 Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

PAD, STEERING 1

FN8-6143D-01-00

1
Out of stock

2

PAD, STEERING 2

FN8-6143E-00-00

1
Out of stock

3

NUT

FJ0-61432-00-00

1
Out of stock

4

SCREW

90149-05969-00

1
Out of stock

5

SCREW

90149-03972-00

1
Out of stock
← Steering 1 Electrical 1 →

More Suspension & Wheels diagrams

Need Help Finding the Right Part?

Not sure it fits? Ask before you order — our team will check the part for your machine.

For a faster answer, include:

Year, make and model of your machine

VIN or frame / serial number

OEM part number or a photo of the old part
