Description

Price

1

BOLT, STUD

90116-08M14-00

Unavailable

2

GASKET, MANIFOLD

6K8-13556-A1-00

Unavailable

3

PLATE

6K8-14527-00-00

Unavailable

4

NUT (661)

95380-08600-00

$7.49

5

.. WASHER, PLATE

92990-08600-00

Unavailable

6

MANIFOLD 1

6K8-13641-00-94

Unavailable

7

REED VALVE ASSY

6H5-13610-00-00

Unavailable

8

. REED SET

6H4-W0004-00-00

Unavailable

9

GASKET,VALVE SEAT

6K8-13621-A1-00

Unavailable

10

SCREW, PAN HEAD(6B0)

97885-05016-00

Unavailable

11

WASHER, PLAIN (646)

92990-05600-00

$0.80

12

BOLT(JF7)

97080-06030-00

$5.49

13

WASHER, PLAIN (646)

92990-06600-00

$2.80

14

BOLT, HEXAGON W/W DEEP RECESS

97E95-06555-00

Unavailable

15

WASHER, PLAIN (646)

92990-06600-00

$2.80

16

COVER,CARBURETOR

99999-02621-00

Unavailable

17

COVER, CARBURETOR 2 (6K8-14284-00-98)

6K8-14284-01-98

Unavailable

18

ELEMENT, AIR CLNR

6K8-14451-00-00

Unavailable

19

BOLT, WASHER BASED

90105-05M52-00

Unavailable

20

BOLT (FJ0)

97080-06018-00

Unavailable

21

WASHER, PLAIN (646)

92990-06600-00

$2.80

22

GASKET,AIR COOLER COVER 1

6K8-13674-A1-00

Unavailable

Yamaha WR500P (WAVE RUNNER) 1991 AIR FILTER Diagram

BOLT, STUD

GASKET, MANIFOLD

PLATE

NUT (661)

.. WASHER, PLATE

MANIFOLD 1

REED VALVE ASSY

. REED SET

GASKET,VALVE SEAT

SCREW, PAN HEAD(6B0)

WASHER, PLAIN (646)

BOLT(JF7)

WASHER, PLAIN (646)

BOLT, HEXAGON W/W DEEP RECESS

WASHER, PLAIN (646)

COVER,CARBURETOR

COVER, CARBURETOR 2 (6K8-14284-00-98)

ELEMENT, AIR CLNR

BOLT, WASHER BASED

BOLT (FJ0)

WASHER, PLAIN (646)

GASKET,AIR COOLER COVER 1
