Yamaha WR450FT (WR450F) 5TJ8 2005 TAILLIGHT Diagram

#

Description
Price

1

TAILLIGHT UNIT ASSY

5TJ-84710-00-00

Unavailable

2

BULB

1A2-84714-50-00

$14.49

3

LENS, TAILLIGHT

4GY-84733-00-00

$33.99

4

SCREW, TAPPING(3AH)

97707-40630-00

$8.49

5

GASKET, TAIL LENS

4GY-84723-00-00

$13.49

6

PLATE, FOOTREST

1HX-27415-00-00

$6.99

7

COLLAR

90387-06144-00

$5.60

8

WASHER, PLATE 8221447500

90201-06057-00

$5.60

9

NUT, FLANGE(4MV)

95707-06500-00

$1.23

10

GROMMET 839774310000

90480-14023-00

$7.49

11

CLAMP(74L)

90461-11099-00

$1.54

12

. SCREW, TAPPING

97780-40010-00

Unavailable

13

PLATE, FITTING 3

5TJ-21677-00-00

Unavailable
