Description

Price

1

SHOCK ABSORBER ASSY, REAR

2GC-22200-00-00

Unavailable

2

DAMPER SUB ASSY

2GC-22201-00-00

Unavailable

3

CAP, AIR VALVE

509-23184-L0-00

$6.99

4

BUSH, SHOCK ABSORBER LOWER

4JX-22226-00-00

$51.99

5

CIRCLIP

5DH-23183-00-00

$5.49

6

GUIDE, SPRING 3

33D-22234-00-00

$40.99

7

SEAT, SPRING UPPER

1SL-22213-00-00

$17.49

8

LABEL, WARNING

4AA-22259-80-00

$13.49

9

SPRING (K=56 BLUE)

1SL-22212-20-00

$274.99

10

GUIDE, SPRING 1

2GB-22214-00-00

$37.99

11

GUIDE, SPRING 2

33D-22224-00-00

$23.99

12

COLLAR, DISTANCE

1C3-22253-50-00

$45.99

13

SEAL, DUST

3JE-22475-00-00

$13.49

14

SEAL, RING

4EW-22474-00-00

$6.99

15

BEARING

5UN-22176-00-00

$32.99

16

BUSH

5MV-22184-00-00

Unavailable

17

COLLAR, DISTANCE

1C3-22253-L1-00

Unavailable

18

SEAL, DUST

5NY-22475-00-00

Unavailable

19

BOLT 2

5XE-22242-01-00

Unavailable

20

NUT, S/L FLANGE

95602-10200-00

Unavailable

21

958-69527-00 WASHER, PLAIN

92990-10200-00

Unavailable

22

BOLT 1

5NY-22241-00-00

Unavailable

23

NUT, SELF-LOCKING

90185-10012-00

Unavailable

24

SHOCK BEARING KIT

1SS-W002G-00-00

Unavailable

Yamaha WR450FG (WR450F) 2GC1 2016 REAR SUSPENSION Diagram

SHOCK ABSORBER ASSY, REAR

DAMPER SUB ASSY

CAP, AIR VALVE

BUSH, SHOCK ABSORBER LOWER

CIRCLIP

GUIDE, SPRING 3

SEAT, SPRING UPPER

LABEL, WARNING

SPRING (K=56 BLUE)

GUIDE, SPRING 1

GUIDE, SPRING 2

COLLAR, DISTANCE

SEAL, DUST

SEAL, RING

BEARING

BUSH

COLLAR, DISTANCE

SEAL, DUST

BOLT 2

NUT, S/L FLANGE

958-69527-00 WASHER, PLAIN

BOLT 1

NUT, SELF-LOCKING

SHOCK BEARING KIT
