Yamaha WR400FL (WR400F) 5GS1 1999 RADIATOR HOSE Diagram

#

Description
Price

1

RADIATOR ASSEMBLY

5BF-1240A-00-00

Unavailable

2

RADIATOR ASSEMBLY

5BF-12461-00-00

Unavailable

3

CAP, RADIATOR

4FL-12462-00-00

$62.99

4

DAMPER, LOCATING 1

3GD-24181-00-00

Unavailable

5

PIPE 1

5BE-12481-10-00

Unavailable

6

BOLT, FLANGE(4MY)

95027-06012-00

$3.88

7

O-RING (5U8)

93210-16500-00

$7.49

8

HOSE 1

5BE-12576-00-00

Unavailable

9

HOSE 2

5BE-12577-01-00

Unavailable

10

HOSE 3

5BE-12578-00-00

Unavailable

11

HOSE 4

5BE-12579-02-00

Unavailable

12

PIPE 2

5BE-12482-00-00

Unavailable

13

BOLT, FLANGE(4MY)

95027-06012-00

$3.88

14

O-RING (5U8)

93210-16500-00

$7.49

15

HOSE CLAMP ASSY

90450-28001-00

$14.99

16

HOSE CLAMP ASSY(64X)

90450-22M14-00

Unavailable

17

GROMMET(3RB)

90480-15528-00

Unavailable

18

COLLAR

90387-0614M-00

Unavailable

19

BOLT, SMALL FLANGE

95027-06025-00

Unavailable

20

WASHER, PLATE(36Y)

90201-063J2-00

Unavailable
