Description

Price

1

H0LDER, LEVER 1

38V-82911-00-00

$38.99

2

H0LDER, LEVER L0WER 1

38V-82913-00-00

$23.99

3

LEVER 1

4GY-83912-00-00

$28.99

4

BOLT (2YK1)

90109-06799-00

$4.99

5

NUT, SELF-LOCKING

95617-06100-00

$8.49

6

BOLT(4TW)

97017-05016-00

$3.29

7

BOLT (23X)

90123-08090-00

$16.99

8

NUT

90179-08401-00

Unavailable

9

SWITCH, HANDLE 1

23X-83976-01-00

Unavailable

10

SWITCH, HANDLE 1

5BF-83976-00-00

Unavailable

11

SCREW, PAN HEAD(N15)

98507-04014-00

$1.86

12

LEVER, DECOMPRESSION

583-83981-00-00

$25.99

13

COLLAR, LEVER 1

5BE-83913-00-00

$4.84

14

SCREW, BINDING

98907-05020-00

$8.49

15

NUT, U

95617-05100-00

$9.49

16

HOLDER, LEVER UPPER 1

5BE-82912-00-00

Unavailable

17

H0LDER, LEVER L0WER 1

38V-82913-00-00

$23.99

18

BOLT(4TW)

97017-05016-00

$3.29

19

COVER, DECOMPRESSION WIRE

583-26352-00-00

Unavailable

Yamaha WR400FL (WR400F) 5GS1 1999 HANDLE SWITCH LEVER Diagram

H0LDER, LEVER 1

H0LDER, LEVER L0WER 1

LEVER 1

BOLT (2YK1)

NUT, SELF-LOCKING

BOLT(4TW)

BOLT (23X)

NUT

SWITCH, HANDLE 1

SWITCH, HANDLE 1

SCREW, PAN HEAD(N15)

LEVER, DECOMPRESSION

COLLAR, LEVER 1

SCREW, BINDING

NUT, U

HOLDER, LEVER UPPER 1

H0LDER, LEVER L0WER 1

BOLT(4TW)

COVER, DECOMPRESSION WIRE
