Yamaha WR400FL (WR400F) 5GS1 1999 CRANKSHAFT PISTON Diagram

#

Description
Price

1

CRANKSHAFT ASSY

5GS-11400-01-00

Unavailable

2

CRANK 1

5JG-11412-00-00

Unavailable

3

CRANK 2

5JG-11422-00-00

Unavailable

4

PIN, CRANK 1

5TG-11681-01-00

$83.99

5

BEARING

93310-63412-00

$131.99

6

ROD, CONNECTING

5BE-11651-10-00

Unavailable

7

BEARING

93306-30633-00

$101.99

8

GEAR, DRIVE

5BE-11536-00-00

Unavailable

9

KEY, STRAIGHT (3L5)

90282-05034-00

$9.49

10

SHAFT 1

5BE-11455-00-00

Unavailable

11

WEIGHT 1

5BE-11454-00-00

Unavailable

12

GEAR, BALANCE WT

5BE-11531-00-00

Unavailable

13

SCREW(2VK)

90149-06250-00

$8.49

14

BEARING(37F)

93306-20335-00

$35.99

15

BEARING, CYLINDRICAL(3YL)

93311-62574-00

$62.99

16

NUT, HEXAGON

90170-14171-00

Unavailable

17

WASHER, LOCK (2K6)

90215-14204-00

Unavailable

18

KEY WOODRUFF 146115450000

90280-03017-00

Unavailable

19

PISTON (STD)

5GR-11631-00-00

Unavailable

20

PISTON RING SET (STD)

5BE-11603-00-00

Unavailable

21

PIN, PISTON

5GR-11633-01-00

Unavailable

22

CIRCLIP

93420-18082-00

Unavailable
