Yamaha WR250ZF (WR250Z) 4JW1 1994 CRANKSHAFT - PISTON Diagram

#

Description

Price

1

PISTON STD

4EW-11631-01-A0

Unavailable

1

PISTON STD

4EW-11631-01-B0

Unavailable

1

PISTON STD

4EW-11631-01-C0

Unavailable

1

PISTON STD

4EW-11631-01-D0

Unavailable

2

PISTON RING SET (STD)

4JX-11603-00-00

$83.99

3

PIN, PISTON

2VM-11633-01-00

Unavailable

4

CIRCLIP (2F1)

93450-19052-00

$7.49

5

BEARING,CON-ROD SMALLEND(2X5)

93310-418E9-00

$48.99

6

CRANKSHAFT ASSEMBLY

4JX-11400-00-00

Unavailable

7

. CRANK 1

4JX-11412-00-00

Unavailable

8

. CRANK 2

4JX-11422-00-00

Unavailable

9

PIN, CRANK 1

4SR-11681-00-00

Unavailable

10

ROD, CONNECTING

5X5-11651-03-00

Unavailable

11

BEARING, CYLINDRICAL(4JW)

93310-425P2-00

Unavailable

12

WASHER 275116850000

90209-25085-00

$12.49

13

BEARING(4GY)

93306-37804-00

Unavailable

14

OIL SEAL(1LX)

93102-22363-00

Unavailable

15

KEY WOODRUFF 146115450000

90280-03017-00

Unavailable

16

BEARING(4GY)

93306-37804-00

Unavailable

17

OIL SEAL (434)

93103-40091-00

Unavailable
