Yamaha WR250FS (WR250F) 5UM5 2004 FUEL TANK Diagram

#

Description
Price

1

FUEL TANK COMP.

5TJ-24110-50-00

Unavailable

2

CAP ASSY

5NY-24610-10-00

$61.99

3

PIPE 5

5RB-24315-00-00

$7.99

4

PIPE JOINT ASSY

3XJ-24380-00-00

$36.99

5

HOSE (L420)

90445-092K1-00

$12.49

6

HOLDER, DAMPER

5XE-24144-00-00

$23.99

7

GROMMET(4AA)

90480-18549-00

$10.49

8

BOLT, WASHER BASED(JA9)

90105-06696-00

$9.49

9

BOLT 1

5XE-24176-10-00

$6.99

10

WASHER, SPECIAL

5NY-24186-00-00

$20.99

11

SCREW, BINDING

98907-06025-00

$8.49

12

BAND, TANK FITTING 1

5SF-24173-00-00

$34.99

13

BRACKET, SEAT

4EW-2412F-00-00

$14.49

14

SCREW, FLAT

98707-06025-00

$8.49

15

DAMPER, LOCATING 1

5TJ-24181-00-00

Unavailable

16

FUEL COCK ASSY 1

2GU-24500-02-00

Unavailable

17

SEAL, COCK

3AJ-24534-01-00

Unavailable

18

SCREW, PAN HEAD (J10)

98580-03008-00

Unavailable

19

O-RING

4X8-24512-00-00

Unavailable

20

VALVE PACKING

3AC-24523-00-00

Unavailable

21

HOSE (L185)

90445-11185-00

Unavailable

22

CLIP

90467-100A1-00

Unavailable

23

WASHER, PLATE(3MB)

90202-05187-00

Unavailable

24

SCREW 256241430000

90149-06011-00

Unavailable

25

DAMPER, LOCATING 3

5NY-24183-00-00

Unavailable

26

BAND

1UA-82591-00-00

Unavailable

27

DAMPER, LOCATING 2

5BE-24182-00-00

Unavailable

28

GRAPHIC SET

5TJ-24240-10-00

Unavailable
