Yamaha WR250FP (WR250F) 5PH5 2002 OIL PUMP Diagram

OIL PUMP ASSY

5SG-13300-01-00

$167.99

PIN, DOWEL(1HX)

93603-16219-00

$8.49

ROTOR ASSY 2

5NL-13320-00-00

$47.99

CIRCLIP(1WG)

93440-10153-00

$2.39

PIN, DOWEL

99530-08012-00

Unavailable

BOLT,SOCKET

91317-06025-00

$5.60

BOLT, SOCKET

91314-06030-00

$8.49

O-RING (371)

93210-10197-00

$7.49

PIN, DOWEL(3VD)

99530-10114-00

$2.55

SHAFT, IDLE GEAR

5BE-13342-00-00

$22.99

GEAR, OIL PUMP IDLE

5NL-13341-00-00

Unavailable

CIRCLIP(2R6)

99001-08600-00

$8.49

WASHER PLATE 164185720000

90201-12166-00

$9.49

CIRCLIP(10Y)

99009-12400-00

$3.59

HOUSING, STRAINER

5NL-13412-00-00

Unavailable

STRAINER, OIL

5NL-13411-00-00

Unavailable

BOLT, SMALL FLANGE

95027-06025-00

Unavailable

HOSE, OIL 1

5NL-13464-00-00

Unavailable

O-RING (371)

93210-10197-00

$7.49

PIN, DOWEL(3VD)

99530-10114-00

$2.55

BOLT, SMALL FLANGE

95027-06025-00

Unavailable

HOSE CLAMP ASSY(64X)

90450-22M14-00

Unavailable

PIPE, OIL 1

5NL-13416-00-00

Unavailable

BOLT, FLANGE(3DM)

95024-06020-00

Unavailable

O-RING (371)

93210-10197-00

$7.49

PIN, DOWEL(3VD)

99530-10114-00

$2.55

HOSE, OIL 2

5NL-13465-00-00

Unavailable

BOLT, SMALL FLANGE

95027-06025-00

Unavailable
