Kawasaki W800 CAFE Transmission Diagram
#
Description
Price
13127
SHAFT-TRANSMISSION INPUT
13127-0087
$239.47
13128
SHAFT-TRANSMISSION OUTPUT
13128-0063
$234.25
13144
SPROCKET-OUTPUT,15T
13144-0554
$46.38
13260
GEAR,INPUT 2ND,22T
13260-1783
$126.54
13260A
GEAR,INPUT 4TH,28T
13260-1785
$126.54
13260B
GEAR,INPUT TOP,27T
13260-1786
$131.18
13260C
GEAR,OUTPUT 2ND,35T
13260-1788
$126.54
13260D
GEAR,OUTPUT 3RD,31T
13260-1789
$126.54
13262
GEAR,OUTPUT LOW,40T
13262-0843
$134.19
13262A
GEAR,OUTPUT 4TH,28T
13262-0845
$134.19
13262B
GEAR,OUTPUT TOP,23T
13262-0846
$134.19
13262C
GEAR,INPUT 5TH,27T
13262-1385
$126.54
13262D
GEAR,INPUT 3RD,25T
13262-1386
$168.51
13262E
GEAR,INPUT 3RD,25T
13262-1458
$162.49
92026
SPACER,20.5X33X1.0
92026-1528
$5.00
92026A
SPACER,25.3X39X2.0
92026-1529
$10.90
92026B
SPACER,TOOTHED,28X30X2.0
92026-1530
$10.90
92028
BUSHING,INPUT GEAR
92028-1449
$25.59
92028A
BUSHING,OUTPUT GEAR
92028-1707
$80.75
92028B
BUSHING,INPUT TOP GEAR
92028-1752
$36.12
92028C
BUSHING,26X34X16.6
92028-180
$28.82
92033
RING-SNAP,20MM
92033-015
$4.26
92033A
RING-SNAP,25.9X30.6X1.2
92033-1037
$4.65
92045
BEARING-BALL,6305N2SH2
92045-1224
$36.90
92046
BEARING-NEEDLE,KMJ20X26X13.8X1
92046-1185
$18.61
92152
COLLAR,SPROCKET
92152-1148
$33.41
92200
WASHER
92200-0863
$3.72
92200A
WASHER,28.5X34.0X1.5
92200-1240
$10.28
92200B
WASHER,29.9X40X1.5
92200-1278
$11.99
92210
NUT,SPROCKET
92210-1098
$34.11
480
CIRCLIP
480J2900
$6.22
600
BALL-STEEL,5/32
600A0500
$0.81
