Suzuki VZR1800M4 (2025) HANDLEBAR Diagram

#

Description
Price

1

HANDLEBAR

56110-48G01

$218.10

2

MIRROR ASSY,REAR VIEW RH

56500-14G20

$162.17

3

MIRROR ASSY,REAR VIEW LH

56600-14G20

$162.17

4

CABLE ASSY,CLUTCH

58200-48G11

$69.14

5

STOPPER,CLUTCH CABLE NO.1

58634-48G00

$15.42

6

STOPPER,CLUTCH CABLE NO.2

58635-48G01

$14.03

7

CABLE ASSY,THROTTLE NO.1

58300-48G41

$51.82

8

CABLE ASSY,THROTTLE NO.2

58300-48G51

$51.32

9

GUIDE,CABLE NO.2

58620-48GC0

Unavailable

10

BOLT

01550-0612A

$1.97

11

CLIP

09408-00244

$2.83
