Suzuki VZR1800BZL9 (2019) REAR FENDER (VZR1800BZL9 E33) (AV4) Diagram

#

Description
Price

1

FENDER, REAR (RED/BLACK)

63110-48G80-AV4

$1,392.37

2

.EMBLEM, SUZUKI (GRAY/BLACK)

68161-44GA0-AA3

$9.87

3

.TAPE SET, REAR FENDER

68170-48G00-BQ4

$63.48

4

CUSHION,RR FENDER RR COVER

63117-39G00

$4.65

5

NUT COWL

94484-24F00

$4.03

6

SCREW (6X16)

09139-06139

$3.23

7

SPACER (6.5X10X9.4)

09180-06286

$2.50

8

CUSHION

09320-10045

$3.76

9

SCREW (6X20)

09139-06190

$4.17

10

CUSHION (9X18X9.5)

09320-09016

$1.97

11

COVER,RR FENDER RH (RED)

63171-48G51-YYG

$257.50

12

COVER,RR FENDER LH (RED)

63181-48G51-YYG

$279.92

13

CUSHION

15439-70G10

$4.33

14

CUSHION

47161-19C00

$3.03

15

CUSHION,FUEL TANK COVER This part replaces 44276-29G00.

44276-29G01

$3.56

16

CLIP (5.9X20.5,BLACK)

09409-06314-5PK

$2.78

17

CUSHION (8X26X7)

09320-08028

$3.04

18

SCREW

03541-0516A

$1.49

19

COLOR:KEL=YVB(BLACK)/YSF(BLUE) | COLOR :

SPECIAL NOTE

Unavailable

19

COLOR:KEL=YVB(BLACK)/YSF(BLUE) | AV4=YYG(RED),YVB(BLACK)

SPECIAL NOTE

Unavailable
