Suzuki VZR1800BZL8 (2018) REAR FENDER (VZR1800BZL8 E33) (JRU) Diagram

#

Description
Price

1

FENDER

63110-48G80-JRU

$796.33

2

.EMBLEM

68161-44GA0-JRU

Unavailable

3

.TAPE SET

68170-48G00-A7Q

$68.58

4

CUSHION,RR FENDER RR COVER

63117-39G00

$4.65

5

NUT COWL

94484-24F00

$4.03

6

SCREW (6X16)

09139-06139

$3.23

7

SPACER (6.5X10X9.4)

09180-06286

$2.50

8

CUSHION

09320-10045

$3.76

9

SCREW (6X20)

09139-06190

$4.17

10

CUSHION (9X18X9.5)

09320-09016

$1.97

11

COVER,RR FENDER RH (BLACK)

63171-48G51-YVB

$213.09

12

COVER,RR FENDER LH (BLACK)

63181-48G51-YVB

$250.68

13

CUSHION

15439-70G10

$4.33

14

CUSHION

47161-19C00

$3.03

15

CUSHION,FUEL TANK COVER This part replaces 44276-29G00.

44276-29G01

$3.56

16

CLIP (5.9X20.5,BLACK)

09409-06314-5PK

$2.78

17

CUSHION (8X26X7)

09320-08028

$3.04

18

SCREW

03541-0516A

$1.49

19

COLOR:KEL=YVB(BLACK)/YSF(BLUE) | COLOR :

SPECIAL NOTE

Unavailable

19

COLOR:KEL=YVB(BLACK)/YSF(BLUE) | JRU=YMD(SILVER),YVB(BLACK)

SPECIAL NOTE

Unavailable
