Suzuki VZR1800 (2009) TURNSIGNAL LAMP (VZR1800K8/K9/NK8/NK9) Diagram

#

Description
Price

1

LAMP ASSY, FRONT TURNSIGNAL, R

35601-38AF0

$151.52

1

LAMP ASSY, FRONT TURNSIGNAL, L | Includes Item(s) 2 - 5

35602-38AF0

$107.97

2

LENS | FOR RH

35610-38AA0

$28.79

3

LENS | FOR LH

35630-38AA0

$29.21

4

SCREW (4X10)

35623-38AA0

$4.67

5

BULB (12V,21/5W) This part replaces 09471-12083.

09471-12128

$6.08

6

SCREW, FR TURNSIGNAL LAMP

02142-0612A

$1.37

7

CUSHION, FR TURNSIGNAL COVER

09320-09016

$1.97

8

SCREW, FR TURNSIGNAL LAMP STAY

03541-0510A

$1.43

9

STAY, FR TURNSIGNAL

35641-48G00

$211.80

10

SCREW, FR TURNSIGNAL COVER

09139-06146

$2.80

11

LAMP ASSY,RR TURNSIGNAL RH This part replaces 35603-48EC0.

35603-48EC1

$104.10

11

LAMP ASSY,RR TURNSIGNAL LH | Includes Item(s) 12 - 15 This part replaces 35604-38AE0.

35604-38AE1

$113.63

12

LENS | FOR RH

35630-38AE1

$29.21

13

LENS | FOR LH

35610-38AE1

$28.79

14

SCREW (4X10)

35623-38AA0

$4.67

15

BULB (12V21W)

09471-12045

$2.95

16

SPACER, REAR TURNSIGNAL LAMP

35695-17C00

$3.69

17

WASHER, REAR TURNSIGNAL | 10.5X30X2.3

09160-10501

$2.33

18

NUT, REAR TURNSIGNAL LAMP

08310-0010A

$1.86

19

RELAY ASSY,TURNSIGNAL LAMP This part replaces 38610-03F00.

38610-03F01

$81.99
