Suzuki VZR1800 (2009) REAR FENDER (VZR1800K8/NK8) Diagram

#

Description
Price

1

FENDER,REAR This part replaces 63110-48G00-YAY.

63110-48G01-YAY

$361.75

1

FENDER,REAR This part replaces 63110-48G00-YHG.

63110-48G01-YHG

$334.93

1

FENDER, REAR (ORANGE) | VZR1800K8; Includes Item(s) 2

63110-48G00-YME

Unavailable

2

EMBLEM,"SUZUKI" This part replaces 68641-19F00-YD8.

68641-19F01-YD8

$10.30

3

CUSHION, LAMP

63117-39G00

$4.65

4

NUT COWL

94484-24F00

$4.03

5

BOLT, FRONT

09139-06030

$3.70

6

SPACER

09180-06286

$2.50

7

CUSHION

09320-10045

$3.76

8

BOLT, CENTER

09139-06120

$2.83

9

BOLT, REAR

09139-06126

$4.04

10

CUSHION

09320-09016

$1.97

11

COVER,REAR FEND This part replaces 63171-48G00-YAY.

63171-48G01-YAY

$199.43

11

COVER,RR FENDER This part replaces 63171-48G00-YHG.

63171-48G01

$61.77

11

COVER,RR FENDER | VZR1800K8 This part replaces 63171-48G00-YME.

63171-48G01

$61.77

12

COVER,REAR FEND This part replaces 63181-48G00-YAY.

63181-48G01-YAY

Unavailable

12

COVER,RR FENDER This part replaces 63181-48G00-YHG.

63181-48G01

$53.50

12

NO DESCRIPTION AVAILABLE | VZR1800K8 This part replaces 63181-48G00-YME.

63181-48G01-YME

Unavailable

13

CUSHION, RH

15439-70G10

$4.33

14

CUSHION, LH

47161-19C00

$3.03

15

CUSHION,FUEL TANK COVER This part replaces 44276-29G00.

44276-29G01

$3.56

16

CLIP (BLACK)

09409-06314-5PK

$2.78

17

CUSHION

09320-08028

$3.04

18

SCREW

03541-0516A

$1.49
