Description

Price

1

LAMP ASSY, REAR COMB

35710-48G70

$410.97

2

WASHER, REAR COMB

09160-05501

$1.84

3

CUSHION This part replaces 09320-10054.

09320-10073

$2.27

4

SCREW, REAR COMB

03541-0512A

$1.49

5

LAMP ASSY, LICENSE | Includes Item(s) 6 - 9 This part replaces 35910-41G00.

35910-41G02

$73.97

6

LENS, LICENSE This part replaces 35912-41G00.

35912-41G01

$13.28

7

GASKET

35913-41G00

$14.23

8

COVER, LICENSE LAMP

35917-41G00

$35.32

9

BULB (12V5W) This part replaces 09471-12140.

09471-12058

$2.33

10

WASHER, LICENSE LAMP | 6.5X20X1.2

09160-06077

$1.91

11

SPACER, LICENSE LAMP | 6.5X9X8

09180-06261

$1.91

12

NUT, LICENSE LAMP

08316-1006A

$2.19

13

REFLECTOR ASSY, RR SIDE This part replaces 35970-07F00.

35970-07F01

$20.88

14

NUT, REAR SIDE RR

08316-1005A

$2.19

15

BRACKET, REAR SIDE RR, R

35975-48G00

Unavailable

16

BRACKET, REAR SIDE RR, L

35976-48G00

$7.42

17

SCREW, REAR SIDE RR BRKT

02162-0612A

$2.05

18

CUSHION,HELMET BOX (60X60X3.0 | 60X60X3.0

92213-33G00

$5.99

19

CLAMP (L:45)

09404-06429

$1.83

19

CLAMP(L:62) This part replaces 09404-10204.

09404-10206

$2.35

Suzuki VZR1800 (2009) REAR COMBINATION LAMP (VZR1800ZK7/ZK8) Diagram
