Suzuki VZR1800 (2009) HANDLEBAR (MODEL K9) Diagram

#

Description
Price

1

HANDLEBAR This part replaces 56110-48G00.

56110-48G01

$218.10

2

MIRROR ASSY, REAR VIEW RH This part replaces 56500-14G11.

56500-14G20

$162.17

3

MIRROR ASSY, REAR VIEW LH This part replaces 56600-14G11.

56600-14G20

$162.17

4

CABLE ASSY, CLUTCH This part replaces 58200-48G10.

58200-48G11

$69.14

5

STOPPER, CLUTCH CABLE NO.1

58634-48G00

$15.42

6

STOPPER, CLUTCH CABLE NO.2 This part replaces 58635-48G00.

58635-48G01

$14.03

7

CABLE ASSY,THRO This part replaces 58300-48G20.

58300-48G21

$71.45

8

CABLE ASSY, THROTTLE NO.2

58300-48G30

$72.82

9

GUIDE, CABLE NO.1 | VZR1800

58620-48G20

Unavailable

9

GUIDE, CABLE NO.1 | VZR1800N

58620-48G10

Unavailable

10

GUIDE, CABLE NO.2

58620-48GB0

Unavailable

11

BOLT

01550-0612A

$1.97

12

CLIP

09408-00244

$2.83
