Suzuki VZ1600 (CA) (2005) CHASSIS ELECTRICAL EQUIPMENT Diagram

#

Description

Price

14091

COVER,CONNECTOR

K1409-10236

Unavailable

21061

RECTIFIER

K2106-11003

Unavailable

26006

FUSE,30A-G

K2600-61006

Unavailable

26006A

FUSE,10A-R

K2600-61007

Unavailable

26006B

FUSE,15A-B

K2600-61061

Unavailable

26011

WIRE-LEAD,BATTERY(+)

K2601-10018

Unavailable

26011A

WIRE-LEAD,BATTERY(-)

K2601-11750

Unavailable

26012

BATTERY ASSY This part replaces K2601-21371.

33610-03G10

$143.65

26021

JUNCTION BOX

K2602-10002

Unavailable

26030

HARNESS,SUB

K2603-01450

Unavailable

26031

HARNESS,MAIN

K2603-10228

Unavailable

27002

RELAY-ASSY

K2700-21051

$51.98

27002A

RELAY-ASSY,SIGNAL LAMP

K2700-21113

Unavailable

27003

HORN

K2700-31431

Unavailable

49016

COVER-SEAL,FUSE

K4901-60005

Unavailable

92037

CLAMP,L=60

K9203-71069

Unavailable

92037A

CLAMP

K9203-71173

Unavailable

92160

DAMPER,JUNCTION BOX

K9216-01650

Unavailable

92171

CLAMP,IGNITION COIL,LH

K9217-10204

Unavailable

92171A

CLAMP,COUPLER

K9217-10231

Unavailable

92171B

CLAMP,HARNESS

K9217-11269

Unavailable

92171C

CLAMP,IGNITION COIL,RH

K9217-11370

Unavailable

92171D

CLAMP,DIA=13

K9217-11415

Unavailable

92171E

CLAMP,DIA=10

K9217-11423

Unavailable

92171F

CLAMP,DIA=15

K9217-11424

Unavailable

130

BOLT-FLANGED

KK130-J0612

Unavailable

130A

BOLT-FLANGED,6X10

KK130-V0610

Unavailable
