2005 Suzuki VZ1600 (CA) AIR Cleaner Diagram

← All diagrams

Find the part on the AIR Cleaner diagram for your 2005 Suzuki VZ1600 (CA), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2005 Suzuki VZ1600 (CA) AIR Cleaner Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

11011

CASE-AIR FILTER

K1101-10009

2
Out of stock

11011A

CASE-AIR FILTER,LH

K1101-11601

1
Out of stock

11013

ELEMENT-AIR FILTER

K1101-31248

1
Out of stock

11038

CASE-ASSY-AIR FILTER,RH

K1103-80005

1
Out of stock

11053

BRACKET

K1105-30231

1
Out of stock

11060

GASKET,AIR FILTER CASE

K1106-01968

2
Out of stock

14073

DUCT,AIR FILTER

K1407-31739

1
Out of stock

16126

VALVE,AIR CUT

K1612-61437

1
Out of stock

39045

DUCT-ASSY,CENTER

K3904-50003

1
Out of stock

52014

ELBOW

K5201-41083

1
Out of stock

56052

MARK

K5605-20227

2
Out of stock

92002

BOLT,6X16

K9200-21570

2
Out of stock

92002A

BOLT,M6X14X13.5

K9200-21595

3
Out of stock

92009

SCREW,TAPPING,5X16

K9200-91264

2
Out of stock

92009A

SCREW,5X20

K9200-91905

4
Out of stock

92037

CLAMP

K9203-71468

1
Out of stock

92037A

CLAMP,TUBE

KK920-37147

2

$5.88

In stock

92037B

CLAMP

K9203-71593

1
Out of stock

92066

PLUG,DRAIN

K9206-61211

1
Out of stock

92071

GROMMET,AIR FILTER

K9207-11042

1
Out of stock

92071A

GROMMET,AIR FILTER

K9207-11114

1
Out of stock

92093

SEAL,AIR FILTER CASE

K9209-31408

1
Out of stock

92093A

SEAL,DUCT,LH

K9209-31459

1
Out of stock

92093B

SEAL

K9209-31485

1
Out of stock

92093C

SEAL,DUCT,RH

K9209-31491

1
Out of stock

92151

BOLT,8X14

K9215-11438

2
Out of stock

92160

DAMPER

K9216-01594

3
Out of stock

92161

DAMPER

K9216-10002

1
Out of stock

92170

CLAMP

K9217-01017

3
Out of stock

92170A

CLAMP,TUBE

K9217-01445

1
Out of stock

92170B

CLAMP

K9217-01695

1
Out of stock

92191

TUBE,BREATHER

K9219-11820

1
Out of stock

92192

TUBE,FR HEAD-AIR SWITCH

K9219-20001

1
Out of stock

92192A

TUBE,RR HEAD-AIR SWITCH

K9219-20002

1
Out of stock

92192B

TUBE,AIR SWITCH-AIR CLEANER

K9219-20003

1
Out of stock

92200

WASHER,8.5X20X1.6

K9220-01463

2
Out of stock

120

BOLT-SOCKET

KK120-S0616

4
Out of stock

702

TUBE-RUBBER,7X10X1000

KKK70-2A071

1
Out of stock
