Yamaha VX700XTCPB (VMAX 700 XTCP (PLASTIC SKI, 1.5"TRACK)) 8DL1 1998 FUEL TANK Diagram

TANK, FUEL

8CW-24111-00-00

Unavailable

GAS CAP ASSY, W/O GAUGE

8CW-24610-01-00

Unavailable

GASKET, CAP

8CW-24612-00-00

$17.49

PIPE, JOINT 1

8CR-24376-01-00

$5.49

GROMMET

8CR-24339-00-00

$5.49

FILTER ASSY

8H5-24560-00-00

Unavailable

TUBE, FLEXIBLE VINYL(8AK)

91A20-07039-00

$5.60

SENDER UNIT ASSY, FUEL METER

8CW-85752-00-00

Unavailable

O-RING (102)

93210-41041-00

$7.49

SCREW, BINDING

98907-05008-00

$2.18

CLIP (7K7)

90467-11044-00

$8.49

PIPE, FUEL 1

8CR-24311-01-00

Unavailable

CLIP (7K7)

90467-11044-00

$8.49

PIPE, JOINT 1

8CR-24376-01-00

$5.49

PIPE, FUEL 1

8CR-13971-00-00

Unavailable

SPRING, COMPRESSION (10L)

90501-08668-00

Unavailable

TUBE, FLEXIBLE VINYL(8AT)

91A20-05145-00

Unavailable

CLIP (8A1)

90467-09026-00

Unavailable

NUT, NYLON

95717-08300-00

Unavailable

WASHER, PLATE (3L7)

90201-08784-00

Unavailable

CLAMP(4FM)

90464-15195-00

Unavailable
