Description

Price

1

GEAR 1

8DM-1760A-18-00

Unavailable

2

BOLT,CAP

8DV-17617-10-00

$4.63

3

. CLAMP

90465-10381-00

Unavailable

4

CLAMP(4FM)

90464-15195-00

$4.41

5

CLAMP(4FM)

90464-15195-00

$4.41

6

DAMPER

8CW-82176-00-00

Unavailable

7

PIPE (L320)

8CW-8235W-01-00

Unavailable

8

CLIP(41W)

90467-08092-00

$9.49

9

. BRACKET, BATTERY

8CW-2199G-00-00

Unavailable

10

BOLT, FLANGE

95817-06014-00

Unavailable

11

. SHIELD, HEAT

8CW-2199H-00-00

Unavailable

12

SEAT, BATTERY

84N-82122-00-00

$6.99

13

BAND, BATTERY

8CY-82131-00-00

$12.99

14

WIRE, PLUS LEAD

8DY-82115-00-00

Unavailable

15

. WIRE, SUB LEAD

8DY-82509-00-00

Unavailable

16

STARTER RELAY ASSY (RC19-016)

3EL-81940-02-00

Unavailable

17

BOLT, SMALL FLANGE

95027-06008-00

Unavailable

18

COVER, BATTERY

8DX-82129-01-00

Unavailable

19

. HOLDER, RELAY

8CY-81952-00-00

Unavailable

20

YB16ALA2 YUASA BATTERY

YB1-6ALA2-00-00

Unavailable

21

STARTING MOTOR KIT

8CR-W8180-15-KT

Unavailable

Yamaha VX500ERC (VMAX 500 DELUXE) 8DT2 1999 ELECTRICAL 2 Diagram

GEAR 1

BOLT,CAP

. CLAMP

CLAMP(4FM)

CLAMP(4FM)

DAMPER

PIPE (L320)

CLIP(41W)

. BRACKET, BATTERY

BOLT, FLANGE

. SHIELD, HEAT

SEAT, BATTERY

BAND, BATTERY

WIRE, PLUS LEAD

. WIRE, SUB LEAD

STARTER RELAY ASSY (RC19-016)

BOLT, SMALL FLANGE

COVER, BATTERY

. HOLDER, RELAY

YB16ALA2 YUASA BATTERY

STARTING MOTOR KIT
