2025 Yamaha VX (VX1050FB) Control Cable Diagram

← All diagrams

Find the part on the Control Cable diagram for your 2025 Yamaha VX (VX1050FB), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2025 Yamaha VX (VX1050FB) Control Cable Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

CABLE, STEERING

F4N-61481-01-00

1

$485.99

In stock

2

. PACKING C

F1B-61438-00-00

1

$2.57

In stock

3

NUT

F1B-6151S-01-00

1

$14.49

In stock

4

. STUD, JOINT BALL

F1B-61461-02-00

1

$85.53

In stock

5

. BALL JOINT ASSY

F2N-61460-00-00

1

$48.49

In stock

6

WASHER, PLATE

90201-06906-00

1

$3.23

In stock

7

NUT

9538R-06700-00

1
Out of stock

8

MOTOR ASSY

F4N-6140B-13-00

1

$619.99

In stock

9

. HOUSING

F4S-6152K-00-00

1

$299.98

In stock

10

. SEAL

F4P-63262-00-00

1

$26.92

In stock

11

. PLUG

F3J-613D0-00-00

1

$11.99

In stock

12

. BOLT, STUD

F3J-67369-00-00

1

$6.46

In stock

13

. COVER

F3Y-6143J-00-00

1

$52.99

In stock

14

. SCREW

F3Y-68198-00-00

1

$3.69

In stock

15

. CONTROL UNIT

F4N-68197-01-00

1

$872.49

In stock

16

. COLLAR

90387-06119-00

1

$4.13

In stock

17

DAMPER, IGNITION C

6A0-82317-01-00

1

$6.31

In stock

18

. BOLT

F3J-613B4-20-00

1

$4.62

In stock

19

. PLATE

F4P-61256-00-00

1

$62.99

In stock

20

. BOLT, HEXAGON

F3Y-613B3-00-00

1

$4.62

In stock

21

. SCREW

F3J-68198-20-00

1

$3.69

In stock

22

. WASHER, PLAIN

F3J-613C3-10-00

1

$3.95

In stock

23

. MAGNET, SENSOR

F3J-60428-00-00

1

$25.49

In stock

24

. WIRE HARNESS ASSY

F4N-68270-10-00

1
Out of stock

25

. SCREW

F3J-68198-00-00

1

$3.16

In stock

26

. CLAMP, WIRE

F3J-68273-00-00

1

$3.23

In stock

27

. MOTOR

F4S-68352-00-00

1

$176.99

In stock

28

. BOLT

F3J-613B4-00-00

1

$4.62

In stock

29

. PLATE

F3Y-61348-00-00

1

$4.62

In stock

30

. SCREW

F3J-68198-20-00

1

$3.69

In stock

31

. BOLT

F3J-613B4-10-00

1

$2.19

In stock

32

. SPACER

F3J-61492-00-00

1

$7.38

In stock

33

. GEAR 1

F4P-60211-00-00

1

$117.49

In stock

34

. CLAMP

F4P-68273-00-00

1

$4.15

In stock

35

. O-RING

F4P-613A5-10-00

1

$4.62

In stock

36

SHAFT, 1

F3Y-60221-10-00

1

$21.37

In stock

37

. BUSH

F3Y-61344-00-00

1

$3.95

In stock

38

O-RING

F4P-613A5-00-00

1

$3.55

In stock

39

. BUSH

F4P-61344-00-00

1

$4.74

In stock

40

. SENSOR ANGLE

F4S-85887-00-00

1
Out of stock

41

PLATE

F4P-U8285-00-00

1

$14.60

In stock

42

BOLT, WITH WASHER

90119-06894-00

1

$1.54

In stock

43

BOLT, WITH WASHER

90119-08852-00

1

$4.31

In stock

44

NUT, LOCK

F3Y-U142L-00-00

1

$2.85

In stock

45

SHIFT ARM ASSY

F3Y-6150F-00-00

1

$52.26

In stock

46

. BOLT, JOINT

6R7-42316-00-00

1

$34.49

In stock

47

ROD ASSY 2

F3J-6150D-00-00

1

$41.17

In stock
