Yamaha VX1050EB (VX DELUXE) F4NW 2025 ENGINE HATCH 3 Diagram

#

Description

Price

1

COVER,SIDE 1 (LGB)

F4N-U377B-00-98

$208.99

1

COVER,SIDE 1

F4N-U377B-00-PC

Unavailable

2

SCREW

F3X-U7823-12-00

Unavailable

3

NUT, LOCK

F2N-U142L-00-00

Unavailable

4

BOLT, WITH WASHER

90119-06880-00

Unavailable

5

NUT

F3X-U517E-00-00

Unavailable

6

PLATE, FIX

F2X-U5175-00-00

Unavailable

7

RIVET (EU0)

90267-48938-00

Unavailable

8

PAD, KNEE (LGB)

F4N-U353B-00-98

$132.99

8

PAD, KNEE

F4N-U353B-00-P9

Unavailable

9

SCREW

F3X-U7823-12-00

Unavailable

10

SCREW

F3X-U7823-02-00

Unavailable

11

ORNAMENT LH (LGB)

F4N-U517W-01-98

Unavailable

11

ORNAMENT LH

F4N-U517W-01-PB

$88.99

12

CLIP

F3Y-U153K-00-00

Unavailable

13

COVER,SIDE 2 (LGB)

F4N-U377C-00-98

Unavailable

13

COVER,SIDE 2

F4N-U377C-00-PC

Unavailable

14

SCREW

F3X-U7823-12-00

Unavailable

15

NUT, LOCK

F2N-U142L-00-00

Unavailable

16

BOLT, WITH WASHER

90119-06880-00

Unavailable

17

NUT

F3X-U517E-00-00

Unavailable

18

PLATE, FIX

F2X-U5175-00-00

Unavailable

19

RIVET (EU0)

90267-48938-00

Unavailable

20

PAD, KNEE 1 (LGB)

F4N-U353C-00-98

Unavailable

20

PAD, KNEE 1

F4N-U353C-00-P9

Unavailable

21

SCREW

F3X-U7823-12-00

Unavailable

22

SCREW

F3X-U7823-02-00

Unavailable

23

ORNAMENT RH (LGB)

F4N-U517X-01-98

Unavailable

23

ORNAMENT RH

F4N-U517X-01-PB

Unavailable

24

CLIP

F3Y-U153K-00-00

Unavailable

25

ORNAMENT, MIDDLE L

F4N-U89AA-00-98

Unavailable

25

ORNAMENT, MIDDLE L

F4N-U89AA-00-P9

Unavailable

26

SCREW

F2S-U13C1-00-00

Unavailable

27

ORNAMENT, MIDDLE R

F4N-U89AB-00-98

Unavailable

27

ORNAMENT, MIDDLE R

F4N-U89AB-00-P9

Unavailable

28

SCREW

F2S-U13C1-00-00

Unavailable
