Yamaha VX1050BU (VX CRUISER VX1050BU VX DELUXE) F5T2 2019 ENGINE HATCH 1 Diagram

#

Description
Price

1

HOOK,LID LOCK

F2X-U517F-00-00

Unavailable

2

NUT

F4G-U517E-00-00

Unavailable

3

BOLT, WITH WASHER

90119-06880-00

Unavailable

4

COVER, CENTER

F2X-U5554-00-00

Unavailable

5

BOLT, WITH WASHER

90119-06878-00

Unavailable

6

PLATE, FIX

F2X-U5175-00-00

Unavailable

7

RIVET (EU0)

90267-48938-00

Unavailable

8

. DAMPER 1

F1X-U828E-01-00

Unavailable

9

. GROMMET

90480-19800-00

Unavailable

10

SEAL, COVER CENTER

F2X-U555B-00-00

Unavailable

11

COVER METER

F2X-U8262-00-00

Unavailable

12

SCREW

F2S-U13C1-00-00

Unavailable

13

COVER,SIDE 1 (VPBM6)

F2X-U377B-10-P2

Unavailable

13

COVER,SIDE 1

F2X-U377B-10-P3

Unavailable

14

BOLT,HEX. SOCKET BUTTON

90111-06803-00

Unavailable

15

NUT, LOCK

F2N-U142L-00-00

Unavailable

16

BOLT, WITH WASHER

90119-06878-00

Unavailable

17

PLATE, FIX

F2X-U5175-00-00

Unavailable

18

RIVET (EU0)

90267-48938-00

Unavailable

19

ORNAMENT, SIDE LH

F2X-U377F-00-00

Unavailable

19

ORNAMENT, SIDE LH

F3P-U377F-40-00

Unavailable

20

NUT

F4G-U517E-00-00

Unavailable

21

SCREW

F2N-67823-10-00

Unavailable

22

INNER, COVER SIDE 1

F2X-U377H-00-00

Unavailable

22

INNER, COVER SIDE 1

F2X-U377H-10-00

Unavailable

23

COVER,SIDE 2 (VPBM6)

F2X-U377C-10-P2

Unavailable

23

COVER,SIDE 2

F2X-U377C-10-P3

Unavailable

24

BOLT,HEX. SOCKET BUTTON

90111-06803-00

Unavailable

25

NUT, LOCK

F2N-U142L-00-00

Unavailable

26

BOLT, WITH WASHER

90119-06878-00

Unavailable

27

PLATE, FIX

F2X-U5175-00-00

Unavailable

28

RIVET (EU0)

90267-48938-00

Unavailable

29

ORNAMENT, SIDE RH

F2X-U377G-00-00

Unavailable

29

ORNAMENT, SIDE RH

F3P-U377G-40-00

Unavailable

30

NUT

F4G-U517E-00-00

Unavailable

31

SCREW

F2N-67823-10-00

Unavailable

32

INNER, COVER SIDE 2

F2X-U377J-00-00

Unavailable

32

INNER, COVER SIDE 2

F2X-U377J-10-00

Unavailable

33

BOX GLOVE

F2X-U516P-00-00

Unavailable

34

GLOVE BOX HATCH ASSY.

F2X-U1708-00-00

Unavailable

35

. PACKING CASE

F2X-U519D-00-00

Unavailable

36

LOCK

F2X-U2875-00-00

Unavailable
