Honda VTR1000FA (05) MOTORCYCLE, JPN, VIN# JH2SC360-5M700001 RIGHT CRANKCASE COVER Diagram

#

Description

Price

1

COVER, R.

11330-MBB-A20

Unavailable

2

PLATE, R. COVER

11333-MBB-300

$21.46

4

RUBBER A, R. COVER DAMPER

11335-ML7-300

$9.21

5

GASKET, R. COVER This part replaces 11394-MBT-000.

11394-MBT-020

$25.85

5

GASKET, R. COVER This part replaces 11394-MBT-010.

11394-MBT-020

$25.85

6

CAP, OIL FILLER

15611-KA4-710

$14.40

7

BOLT, FLANGE (6X32) (NSHF)

90007-GHB-690

$1.87

8

BOLT, FLANGE (6X40) (NSHF)

90007-GHB-710

$2.16

9

WASHER, SPECIAL (6MM)

90406-ML7-000

$2.31

10

O-RING (18X3) (ARAI)

91307-KF0-003

$2.92

11

PIN, DOWEL (8X14) (Honda Code 0069310)

94301-08140

$2.25

12

BOLT, FLANGE (6X10) BOLT, FLANGE (6X12)

95701-06010-00

$1.49

13

CLIP, TUBE (B8) CLIP, TUBE (B7)

95002-02080

$1.80

14

BULK HOSE, VACUUM (4.5X1000) (4.5X160) (BULK HOSE: (95005-45008-10M)

95005-45001-10M

$23.47
