Description

Price

1

ARM, GEARSHIFT

24702-MGR-670

$46.09

2

PEDAL, GEARSHIFT (NOT AVAILABLE) This part replaces 24710-MGR-305.

24710-MGR-670

$83.84

2

PEDAL, GEARSHIFT (NOT AVAILABLE)

24710-MGR-670

$83.84

3

COVER, DUST

24724-MBW-D21

$6.49

4

RUBBER, GEARSHIFT PEDAL

24781-KR3-770

$3.15

5

SWITCH ASSY., RR. STOP This part replaces 35350-MGR-671.

35350-MGR-672

$28.59

5

SWITCH ASSY., RR. STOP

35350-MGR-672

$28.59

6

SPRING, STOP SWITCH

35357-MGR-670

$4.20

7

ROD, RR. BRAKE

43451-MGR-670

$16.00

8

NUT, HEX. (6MM) (LEFT HAND THREAD)

45423-KA4-700

$1.48

9

PEDAL, RR. BRAKE This part replaces 46501-MGR-305.

46501-MGR-670

$108.14

9

PEDAL, RR. BRAKE

46501-MGR-670

$108.14

10

ARM, RR. BRAKE MIDDLE (COO)

46510-MGR-305

$45.17

11

SPRING SET, BRAKE PEDAL

46513-KR6-000

$6.59

12

COLLAR, RR. BRAKE PIVOT

46515-MM8-000

$10.53

13

ROD, RR. BRAKE MIDDLE

46540-MGR-670

$42.96

14

PIN, MIDDLE ROD JOINT

46545-MBA-000

$6.14

15

BOLT, TIE ROD

90101-MGR-670

$3.81

16

BOLT, SOCKET (10X54)

90107-MGR-670

$3.67

17

BOLT B, PIVOT

90116-MGR-670

$11.06

18

WASHER (10.3MM)

90521-427-770

$2.17

19

WASHER (15.2X25)

90557-230-000

$2.17

20

CLIP, SWITCH COVER

90601-KAF-003

$2.43

21

CLIP, CABLE (10MM) CLIP, CABLE (8MM)

90690-GHB-641

$1.99

22

DUST SEAL (17X23X3) (NOK)

91206-968-003

$3.44

23

NUT, HEX. (6MM)

94002-06000-0S

$1.19

24

NUT, FLANGE (10MM)

94050-10000

$1.41

25

WASHER, PLAIN (10MM)

94103-10700

$0.86

26

PIN, COTTER (2.0X12)

94201-20120

$0.94

27

PIN, COTTER (2.0X15)

94201-20150

$0.94

28

CIRCLIP (OUTER) (15MM)

94511-15000

$0.62

29

SPRING A, BRAKE ROD

95014-73100

$1.17

30

JOINT B, BRAKE ARM

95015-32001
