Description

Price

1

ARM, GEARSHIFT

24702-MEG-000

$48.15

2

PEDAL, GEARSHIFT (COO) This part replaces 24710-MEG-000.

24710-MEG-305

$64.80

2

PEDAL, GEARSHIFT (COO)

24710-MEG-305

$64.80

3

COVER, DUST

24724-MBW-D21

$6.98

4

RUBBER, GEARSHIFT PEDAL

24781-371-000

$5.13

5

SWITCH ASSY., RR. STOP

35350-MEG-003

$19.01

6

SPRING, STOP SWITCH

35357-KR3-670

$5.12

8

NUT, HEX. (6MM) (LEFT HAND THREAD)

45423-KA4-700

$1.55

9

PEDAL ASSY., RR. BRAKE (COO) This part replaces 46500-MEG-H10.

46500-MEG-306

$104.59

9

PEDAL ASSY., RR. BRAKE (COO)

46500-MEG-306

$104.59

11

SPRING, BRAKE PEDAL

46514-KZ9-000

$5.14

12

COLLAR, RR. BRAKE PIVOT

46515-MM8-000

$11.72

16

BUSH, WASHER

53312-657-000

$6.70

17

BOLT, TIE ROD

90065-MEG-000

$7.78

19

WASHER (10.3MM)

90521-427-770

$2.28

20

CLIP, SWITCH COVER

90601-KAF-003

$2.67

21

DUST SEAL (17X23X3) (NOK)

91206-968-003

$3.69

23

NUT, HEX. (6MM)

94002-06000-0S

$1.49

26

CIRCLIP (OUTER) (15MM)

94511-15000
