Description

Price

1

FILTER SET, OIL | (Optional). This part replaces 15010-MCE-H51.

15010-MKR-305

$18.15

1

FILTER SET, OIL | (Optional).

15010-MKR-305

$18.15

2

PUMP ASSY., OIL | Use from Engine SN 2511555 to 2513519.

15100-MFE-A40

$137.06

2

PUMP ASSY., OIL | Use from Engine SN 2513520.

15100-MFE-A41

$135.49

3

SPROCKET, OIL PUMP DRIVEN (27T)

15134-MEW-920

$35.03

4

CHAIN, OIL PUMP DRIVE (70L) (DAIDO)

15141-MEG-A21

$18.06

5

STRAINER, OIL

15153-MZ6-000

$17.34

6

GASKET, OIL STRAINER

15154-425-000

$7.63

7

COLLAR, O-RING

15155-300-000

$3.31

9

VALVE ASSY., RELIEF | Use up to Engine SN 2511554.

15220-MEG-000

$27.50

9

VALVE ASSY., RELIEF | Use from Engine SN 2511555 to 2513519.

15220-MFE-A40

$43.91

9

VALVE ASSY., RELIEF | Use from Engine SN 2513520.

15220-MFE-A41

$41.51

11

FILTER, OIL (WAKO FILTER) This part replaces 15410-MFJ-D01.

15410-MFJ-D02

$14.16

11

FILTER, OIL (WAKO FILTER)

15410-MFJ-D02

$14.16

12

PIPE, OIL

15510-MY1-000

$31.21

13

BOLT, FLANGE SOCKET (6X14)

90009-MZ8-H00

Unavailable

14

BOSS, OIL FILTER (Honda Code 1243435)

90019-MB0-000

$7.93

15

WASHER (6X2.3)

90488-MB0-000

$4.44

16

O-RING (14.8X2.4) (ARAI)

91303-KF0-003

$1.63

17

O-RING (14.7X2.2)

91302-MGS-D30

$1.96

17

O-RING (14.8X2.2) This part replaces 91313-MB0-003.

91313-MG7-004

$3.52

17

O-RING (14.8X2.2) (Honda Code 3353620)

91313-MG7-004

$3.52

18

OIL SEAL, PIPE

91315-MF5-003

$3.82

19

O-RING (13X2.5)

91319-300-000

$4.84

20

PIN, DOWEL (8X14) (Honda Code 0069310)

94301-08140

$2.76

21

BOLT, FLANGE (6X28)

95701-06028-00

$1.81

22

BOLT, FLANGE (6X45) This part replaces 95701-06045-00.

95701-06045-07

$2.75

22

BOLT, FLANGE (6X45) BOLT, FLANGE (6X60)
