Honda VT1300CXAC (15) MOTORCYCLE, JPN, VIN# JH2SC611-FK500001 STEP (3) Diagram

HORN (LOW)

38120-MFR-671

$79.41

COLLAR, CHAIN CASE

40515-413-000

$2.92

STAY, HORN

50176-MFR-670

$21.85

PIN, STEP BAR JOINT

50603-033-010

$3.30

BAR, R. STEP (COO)

50612-MFR-305

$16.18

BAR, R. STEP (COO) This part replaces 50612-MK7-010.

50612-MFR-305

$16.18

BRACKET, R. STEP

50615-MFR-670

$44.83

SPRING, STEP RETURN

50617-MB1-700

$5.80

COLLAR, STEP BRACKET

50619-MFR-670

$10.20

STOPPER, STEP RUBBER

50619-MK7-010

$14.06

BRACKET, L. STEP

50625-MFR-670

$52.97

BAR, L. STEP (COO)

50642-MFR-305

$16.18

RUBBER, MAIN STEP (COO)

50661-MFR-305

$9.19

RUBBER, MAIN STEP (COO) This part replaces 50661-MK7-000.

50661-MFR-305

$9.19

BRACKET, R. PILLION STEP

50680-MFR-670

$74.77

BRACKET, L. PILLION STEP

50685-MFR-670

$74.77

RUBBER, PILLION STEP (COO)

50710-MFR-305

$25.75

WASHER, PILLION STEP

50712-MFE-670

$3.08

BAR, PILLION STEP (COO)

50715-MFR-305

$22.52

COLLAR, R. STEP

90114-MFR-670

$3.89

COLLAR, L. STEP

90115-MFR-670

$3.69

BOLT, SPECIAL FLANGE (8X23)

90123-KR3-000

$3.67

BOLT, SPECIAL FLANGE (8X90)

90127-126-900

$6.60

BOLT, HEX. (6X12) BOLT, FLANGE (6X12)

92101-06012-0A

$1.49

BOLT, CAP (8X30)

92501-08030-0A

$3.45

NUT, FLANGE (8MM) NUT, FLANGE (10MM)

94050-08000

$1.49

WASHER, PLAIN (6MM) This part replaces 94101-06000.

94101-06800

$1.49

WASHER, PLAIN (6MM) This part replaces 94101-06080.

94101-06800

$1.49

WASHER, PLAIN (6MM) (USED ON TAILLIGHT)

94101-06800

$1.49

WASHER, PLAIN (8MM)

94101-08000

$1.49

PIN, COTTER (1.6X25) This part replaces 94201-16150.

94201-16250

$1.49

PIN, COTTER (1.6X25)

94201-16250

$1.49

PIN, COTTER (2.0X15)

94201-20150

$1.49

PIN A, PILLION STEP

95015-81000

$2.21

BOLT, FLANGE (8X20)

95701-08020-07

$1.87
