Description

Price

1

DAMPER SET, WHEEL

06410-MAZ-000

$54.00

2

AXLE, RR. WHEEL

42301-MFR-670

$61.91

3

COLLAR, RR. WHEEL

42312-MFR-670

$43.56

4

COVER, PULSER RING

42516-MFR-A00

$18.60

5

FLANGE B, FINAL DRIVEN

42614-MCH-000

$231.93

6

COLLAR, RR. AXLE DISTANCE

42620-MFR-670

$31.84

7

COLLAR A, RR. AXLE DISTANCE

42624-MFR-670

$25.62

8

FLANGE SET, FINAL DRIVEN

42630-MCH-000

$268.13

9

WHEEL SUB-ASSY., RR.

42650-MFR-A21

$1,900.75

11

TIRE, RR.

42711-MFR-676

$385.37

12

VALVE, RIM (DUNLOP)

42753-ML7-004

$11.69

13

DISK, RR. BRAKE

43251-MFR-A01

$393.87

14

RING, FR. PULSER (RR.)

44515-MFR-A00

$144.31

15

BOLT, FR. DISK (8X24) (SAGA)

90105-KL8-741

$5.64

16

BOLT, TORX (5X10)

90131-KFK-630

$2.80

17

NUT, U (22MM)

90305-MCF-D01

$7.35

18

NUT, FLANGE (12MM) (FUSE RASHI)

90306-KF0-003

$3.68

19

WASHER (22X38X2.5)

90401-MAZ-000

$5.13

20

CIRCLIP (INNER) (188)

90651-MCH-000

$16.37

21

BEARING, RADIAL BALL (6905RS)

91052-KZ4-J21

$15.94

22

BEARING, RADIAL BALL (6205X2)

91053-MAZ-003

$15.40

23

BEARING, RADIAL BALL (60/28)

91053-MFR-671

$17.18

24

DUST SEAL (35X52X7.5)

91254-MEE-003

$6.60

25

O-RING (61X2)

91302-MA6-003

$4.93

26

O-RING (50.5X3.5) (ARAI)

91358-MG9-003

Unavailable

26

O-RING (50.5X3.5) (ARAI) This part replaces 91358-MG9-004.
