Honda VT1100C2A (07) SHADOW SABRE, USA, VIN# 1HFSC430-7A700001 AIR CLEANER Diagram

#

Description
Price

1

CASE SUB, AIR CLEANER

17210-MM8-020

$68.16

2

COVER, AIR CLEANER HOUSING

17212-MM8-010

$7.46

3

ELEMENT, AIR CLEANER

17215-MM8-020

$28.24

4

GASKET, AIR CLEANER HOUSING COVER

17217-MG8-300

$7.02

5

RUBBER A, CUSHION

17220-MAH-610

Unavailable

6

RUBBER B, CUSHION

17225-MAH-610

$2.04

7

BAND A, CONNECTING TUBE

17254-MAH-611

Unavailable

8

CONNECTING TUBE A

17255-MM8-000

$46.36

9

BAND, AIR CLEANER CONNECTING TUBE (52) This part replaces 17256-MM8-000.

95018-52250

$4.78

10

TUBE B, AIR CLEANER CONNECTING

17258-MM8-300

Unavailable

11

BAND C, CONNECTING TUBE

17259-MM8-000

$15.13

12

PLUG, BREATHER TUBE

17370-419-700

$3.49

13

TANK, STORAGE

17551-MM8-000

Unavailable

14

TUBE A, BREATHER

17552-MCK-A00

$33.38

15

TUBE B, BREATHER

17553-MM8-000

Unavailable

16

CLIP, SUB-TANK HOSE

17724-102-700

Unavailable

17

STAY, FILLER NECK

19111-MM8-000

Unavailable

18

COLLAR, FR. FENDER

61105-KM7-910

$2.88

20

BOLT, FLANGE (6MM)

90116-ME9-000

$3.12

21

SCREW, PAN (4X18)

93500-04018-0G

$0.75

22

SCREW, PAN (4X20)

93500-04020-0G

$0.71

23

SCREW, PAN (4X25)

93500-04025-0G

$0.59

24

SCREW-WASHER (5X16)

93891-05016-07

$1.04

25

CLIP, TUBE (B12)

95002-02120

Unavailable

26

CLIP, TUBE (B12.5)

95002-02130

$1.04

27

BULK HOSE, VINYL (7X11X8000) (7X11X260)

95003-19008-60M

Unavailable

28

BOLT, FLANGE (6X10)

95701-06010-08

$1.46

29

BOLT, FLANGE (6X12)

95701-06012-08

$1.48
