Yamaha VMX540L (V-MAX) 1987 INSTRUMENT PANEL Diagram

#

Description
Price

1

PANEL, INSTRUMENT

81K-77711-01-00

Unavailable

2

PANEL, INSTRUMENT

8M6-77712-00-00

Unavailable

3

PIN, HINGE

8K4-77477-00-00

Unavailable

4

INDICATOR 1

8U9-77741-00-00

Unavailable

5

INDICATOR 2

8U9-77742-00-00

Unavailable

6

EMBLEM 1

81K-77725-00-00

Unavailable

7

INDICATOR 4

8K2-77744-01-00

Unavailable

8

NUT, SPEC''L SHAPE

90179-16251-00

Unavailable

9

LOUVER 1

8M6-77131-00-00

Unavailable

10

LOUVER 2

8M6-77132-00-00

Unavailable

11

SCREW, PAN

98517-05012-00

$4.73

12

WASHER, PLATE (8J0)

90201-05725-00

Unavailable

13

NUT, NYLON

95707-05300-00

$4.24

14

SCREW, TAPPING

90167-05007-00

Unavailable

15

SCREW, PAN HEAD

90157-05M19-00

Unavailable

16

WASHER(3SX)

92907-05100-00

Unavailable

17

WASHER, PLATE 8067717800

90201-05029-00

Unavailable

18

WASHER(3SX)

92907-05100-00

Unavailable

19

NUT, SPRING (2E9)

90183-05013-00

Unavailable

20

SCREW, PAN HEAD(3TJ)

98507-06016-00

Unavailable

21

WASHER, SPRING

92907-06100-00

Unavailable

22

WASHER, PLATE (4L0)

90201-062A8-00

Unavailable

23

ORMNT, INSTR PNL 1PANEL 1

83H-77715-00-00

Unavailable

24

SHIELD 1

8U9-77731-00-00

Unavailable

25

RIVET, BLIND (8K1)

90267-40076-00

Unavailable

26

WASHER, PLATE

90201-042E0-00

Unavailable

27

BRACKET 1

8X6-77721-00-00

Unavailable
