Yamaha VMX12WC (V-MAX 1200 CA) 3JP2 1989 ELECTRICAL 1 Diagram

NEUTRAL SWITCH ASSY

1L9-82540-00-00

$47.99

O-RING (371)

93210-29196-00

$8.49

SCREW, FLAT

98707-05012-00

$1.71

WIRE, LEAD

2JX-82541-00-00

Unavailable

OIL LEVEL GAUGE ASSY

1FK-85720-00-00

Unavailable

BOLT, HEXAGON

97017-06020-00

$4.06

WASHER, SPRING

92995-06100-00

Unavailable

WASHER, PLAIN (646)

92990-06600-00

$2.80

THERMO SWITCH ASSY

3LN-82560-01-00

Unavailable

THERMO UNIT

11H-83591-00-00

$105.99

WIRE,EARTH LEAD 1

4NK-83354-00-00

Unavailable

SCREW, PAN HEAD (713)

98580-04008-00

$5.60

YBS67-4 WASHER, SPRING

92990-04100-00

$0.86

WASHER, PLAIN (646)

92990-04600-00

$5.99

IGNITION COIL ASSY

25G-82310-10-00

Unavailable

SCREW PAN HEAD

98580-06020-00

Unavailable

WASHER, PLAIN (646)

92990-06600-00

$2.80

CORD, HIGH TENSION 1

4X7-82341-00-00

Unavailable

CORD, HIGH TENSION 1

4X7-82341-00-00

Unavailable

PLUG CAP ASSY

4XY-82370-00-00

Unavailable

IGNITOR UNIT ASSY

1FK-82305-09-00

Unavailable

DAMPER, IGNITION COIL

2EN-82317-00-00

Unavailable

COLLAR(2EN)

90387-045R4-00

Unavailable

SCREW, TAPPING(4HP)

97707-40616-00

Unavailable

NUT, SPRING (26H)

90183-04027-00

Unavailable

WASHER(6E1)

92907-04200-00

Unavailable

SENSOR, PRESSURE

22N-82380-10-00

Unavailable

SCREW PAN HEAD

98580-06020-00

Unavailable

WASHER, SPRING

92995-06100-00

Unavailable

WASHER, PLATE

90201-06020-00

Unavailable

FRONT REFLECTOR ASSY

11H-85110-01-00

Unavailable

NUT, HEXAGON

95317-05600-00

Unavailable

WASHER, PLAIN LARGE

92907-05200-00

Unavailable

WASHER(3SX)

92907-05100-00

Unavailable

REAR REFLECTOR ASSY

1FK-85130-00-00

Unavailable

NUT, HEXAGON SMALL

95317-05700-00

Unavailable

. WASHER, PLAIN

92990-05200-00

Unavailable

YBS67-5 WASHER, SPRING

92990-05100-00

Unavailable
