Yamaha VMX12VC (V-MAX CA) 5GKX 2006 FRONT FORK Diagram
#
1
FRONT FORK ASSY (L.H)
5GK-23102-10-00
Unavailable
2
TUBE, OUTER (LEFT)
5GK-23126-10-00
Unavailable
8
INNER TUBE COMP.1
5GK-23110-00-00
Unavailable
9
PISTON, FRONT FORK
5EA-23171-30-00
Unavailable
10
SPINDLE, TAPER
4YR-23173-00-00
Unavailable
11
CYLINDER COMP., FRONT FORK
5GK-23170-00-00
Unavailable
12
SPRING, FRONT FORK
5GK-23141-00-00
Unavailable
15
BOLT, CAP
3LR-23111-00-00
Unavailable
16
O-RING
4V4-23188-L1-00
Unavailable
17
CAP, FRONT FORK
3LR-23168-00-00
Unavailable
18
BOLT, FLANGE
95814-08045-00
Unavailable
19
SPACER
3YF-23118-00-00
Unavailable
20
WASHER, SPRING UPPER
3LR-23149-00-00
Unavailable
21
FRONT FORK ASSY (R.H)
5GK-23103-10-00
Unavailable
22
TUBE, OUTER
5GK-23136-10-00
Unavailable
28
INNER TUBE COMP.1
5GK-23110-00-00
Unavailable
29
PISTON, FRONT FORK
5EA-23171-30-00
Unavailable
30
SPINDLE, TAPER
4YR-23173-00-00
Unavailable
31
CYLINDER COMP., FRONT FORK
5GK-23170-00-00
Unavailable
32
SPRING, FRONT FORK
5GK-23141-00-00
Unavailable
35
BOLT, CAP
3LR-23111-00-00
Unavailable
36
O-RING
4V4-23188-L1-00
Unavailable
37
CAP, FRONT FORK
3LR-23168-00-00
Unavailable
38
SPACER
3YF-23118-00-00
Unavailable
39
WASHER, SPRING UPPER
3LR-23149-00-00
Unavailable
40
UNDER BRACKET COMP.
5GK-23340-20-00
Unavailable
41
BOLT
91314-08032-00
Unavailable
42
COVER
4PU-2331G-00-00
Unavailable
43
COVER, LOWER 1
4KM-23123-01-00
Unavailable
44
FORK SEAL KIT (TWO FORKS)
4PU-W003B-00-00
Unavailable
