Yamaha VMX12NC (V-MAX 1200 CA) 1JH 1985 STAND FOOTREST Diagram

#

Description
Price

1

FRT FOOTREST ASSEMBLY LASS''Y (L.H)

1FK-27410-00-93

Unavailable

2

COVER, FOOTREST

26H-27413-02-00

Unavailable

3

BOLT, SMALL FLANGE

95024-10030-00

$9.49

4

FRT FOOTREST ASSEMBLY RASS''Y (R.H)

1FK-27420-00-93

Unavailable

5

COVER, FOOTREST

26H-27413-02-00

Unavailable

6

BOLT, SMALL FLANGE

95024-10030-00

$9.49

7

RR FOOTREST ASSEMBLY 1

1FK-27430-00-00

Unavailable

8

. COVER, REAR FOOTREST

3H5-27433-00-00

Unavailable

9

NUT, FLANGE(3BM)

95704-10500-00

$4.29

10

BRACKET 2

1FK-27442-00-00

Unavailable

11

BOLT, FLANGE (3JPE)

95024-08016-00

$9.49

12

BOLT, FLANGE(2UJ)

95024-08020-00

$8.49

13

BOLT, SMALL FLANGE

95027-08020-00

$8.49

14

DAMPER, FOOTREST

26H-27414-00-00

Unavailable

15

STOPPER

26H-2743E-00-00

Unavailable

16

RR FOOTREST ASSEMBLY 2

1FK-27440-00-00

Unavailable

17

. COVER, REAR FOOTREST

3H5-27444-00-00

Unavailable

18

NUT, FLANGE(3BM)

95704-10500-00

$4.29

19

BRACKET 3

1FK-27443-00-00

Unavailable

20

BOLT, FLANGE(2UJ)

95024-08020-00

$8.49

21

BOLT, FLANGE (3JPE)

95024-08030-00

Unavailable

22

DAMPER, FOOTREST

26H-27414-00-00

Unavailable

23

STOPPER

26H-2743E-00-00

Unavailable

24

PEDAL, BRAKE

1FK-27211-00-93

Unavailable

25

BOLT (1J7)

90109-06468-00

Unavailable

26

WASHER, SPRING

92995-06100-00

Unavailable

27

SHAFT, BRAKE PEDAL

1FK-27212-00-00

Unavailable

28

SPRING, TENSION (23X)

90506-18305-00

Unavailable

29

JOINT

47X-27222-00-00

Unavailable

30

. NUT

95380-08700-00

Unavailable

31

PIN W/HOLE 307181180000

90240-08013-00

Unavailable

32

WASHER, PLATE 1562722600

90201-08083-00

Unavailable

33

PIN, COTTER

91490-16020-00

Unavailable

34

STAND, MAIN

1UT-27111-01-R4

Unavailable

35

BOLT(1TX)

90109-101E6-00

Unavailable

36

NUT, SELF LOCKING (3G1)

90185-10091-00

Unavailable

37

SPRING, TENSION (4L0)

90506-45222-00

Unavailable

38

STOPPER, MAIN STAND

371-27114-00-00

Unavailable

39

LINK, MAIN STAND

1FK-27115-00-00

Unavailable

40

STAND, SIDE

1FK-27311-00-R4

Unavailable

41

BOLT(1FK)

90109-107A2-00

Unavailable

42

NUT, U

90185-10037-00

Unavailable

43

LINK, SIDE STAND

1FK-27315-00-00

Unavailable

44

SPRING, TENSION (498)

90507-29019-00

Unavailable

45

HOOK, SIDE STAND

1FK-27352-00-00

Unavailable

46

WASHER, PLATE 8221447500

90201-06057-00

Unavailable

47

NUT, SELF-LOCKING

95617-06100-00

Unavailable
