Yamaha VMX12NC (V-MAX 1200 CA) 1JH 1985 FRONT FORK Diagram
#
1
UNAVAILABLE IN PRICE BOOK
1FK-23120-00-0
Unavailable
2
. TUBE, OUTER 1
1FK-23126-00-00
Unavailable
7
WASHER, SPRING UPPER
26H-23149-00-00
Unavailable
8
. UNAVAILABLE IN PRICE BOOK
1FK-23110-00-0
Unavailable
9
SPINDLE, TAPER
(3R4-23173-L0-00)
Unavailable
10
. UNAVAILABLE IN PRICE BOOK FRONT FORK
1FK-23170-00-0
Unavailable
11
. SPRING, FRONT FORK
1FK-23141-00-00
Unavailable
12
O-RING
26H-23147-00-00
Unavailable
14
SCREW, PAN HEAD(3XP)
98517-04006-00
Unavailable
16
BOLT
3R4-23181-L0-00
Unavailable
17
. BOLT, CAP
26H-23111-00-00
Unavailable
18
CAP, FRONT FORK
42H-23168-00-00
Unavailable
19
BOLT, HEXAGON
97017-08060-00
Unavailable
20
NUT(6L2)
95333-08600-00
Unavailable
21
.. WASHER, PLATE
92990-08600-00
Unavailable
22
.. WASHER, PLATE
92990-08600-00
Unavailable
23
. SPACER
1FK-23118-00-00
Unavailable
24
. SEAT, SPRING UPPER
1FK-23142-00-00
Unavailable
25
FRONT FORK ASSY (R.H.)
1FK-23103-00-00
Unavailable
26
. TUBE, OUTER 2
1FK-23136-00-00
Unavailable
31
WASHER, SPRING UPPER
26H-23149-00-00
Unavailable
32
. INNER TUBE COMP 1
1FK-23110-00-00
Unavailable
33
SPINDLE, TAPER
(3R4-23173-L0-00)
Unavailable
34
. CYLINDER COMP, FRONT FORK
1FK-23170-00-00
Unavailable
35
. SPRING, FRONT FORK
1FK-23141-00-00
Unavailable
36
O-RING
26H-23147-00-00
Unavailable
38
SCREW, PAN HEAD(3XP)
98517-04006-00
Unavailable
40
BOLT
3R4-23181-L0-00
Unavailable
41
. BOLT, CAP
26H-23111-00-00
Unavailable
42
CAP, FRONT FORK
42H-23168-00-00
Unavailable
43
. SPACER
1FK-23118-00-00
Unavailable
44
. SEAT, SPRING UPPER
1FK-23142-00-00
Unavailable
45
UNDER BRACKET COMP
1FK-23340-00-00
Unavailable
46
BOLT,SOCKET
91314-08030-00
Unavailable
47
HOSE ASSY
1FK-2318J-00-00
Unavailable
48
O-RING
3J2-23147-00-00
Unavailable
49
AIR VALVE COMP.
23X-23190-L0-00
Unavailable
50
O-RING
26H-23188-00-00
Unavailable
51
CAP, AIR VALVE
10M-23184-01-00
Unavailable
