Description

Price

1

FRAME COMP.

1FK-21110-00-33

Unavailable

2

DOWN TUBE COMP.

1FK-21140-00-33

Unavailable

3

BACK STAY SUB COMP. 1

1FK-21105-00-33

Unavailable

4

CROSS BAR COMPLETE

1FK-2141V-10-00

$93.99

5

STAY, ENGINE 2

1FK-21315-00-00

Unavailable

6

BOLT, SOCKET

91317-10030-00

$9.49

7

NUT

90179-10321-00

Unavailable

8

BOLT, SOCKET

91317-10020-00

$8.49

9

BOLT, SMALL FLANGE

95027-08016-00

$8.49

10

NUT, CROWN (5A8)

90176-10033-00

$9.49

11

BOLT, WASHER BASED(1FK)

90105-10376-00

$7.49

12

BOLT, WASHER BASED (26H)

90105-12252-00

$11.49

13

BOLT, FLANGE

95817-08060-00

$3.76

14

NUT, CROWN (12W)

90176-08040-00

$4.19

15

WASHER(JN5)

92907-08100-00

$8.49

16

BOLT WASHER BASED (1J7)

90105-08066-00

Unavailable

17

UNAVAILABLE IN PRICE BOOK

[90-20108-1H-40

Unavailable

18

COVER

1FK-2117F-01-00

Unavailable

19

COVER 2

1FK-2117M-00-00

Unavailable

20

COVER 3

1FK-2117N-01-00

Unavailable

21

TOOL KIT

26H-W2810-00-00

Unavailable

Yamaha VMX12NC (V-MAX 1200 CA) 1JH 1985 FRAME Diagram

FRAME COMP.

DOWN TUBE COMP.

BACK STAY SUB COMP. 1

CROSS BAR COMPLETE

STAY, ENGINE 2

BOLT, SOCKET

NUT

BOLT, SOCKET

BOLT, SMALL FLANGE

NUT, CROWN (5A8)

BOLT, WASHER BASED(1FK)

BOLT, WASHER BASED (26H)

BOLT, FLANGE

NUT, CROWN (12W)

WASHER(JN5)

BOLT WASHER BASED (1J7)

UNAVAILABLE IN PRICE BOOK

COVER

COVER 2

COVER 3

TOOL KIT
