Suzuki VL800 (2009) TURNSIGNAL FRONT & REAR LAMP (MODEL K7/K8) Diagram

#

Description
Price

1

FRONT TURNSIGNAL ASSY, RH

35601-41FC0

$152.27

2

FRONT TURNSIGNAL ASSY, LH | Includes Item(s) 3 - 6

35602-41FC0

$151.52

3

LENS | FOR RH

35610-38AA0

$28.79

4

LENS | FOR LH

35630-38AA0

$29.21

5

SCREW

35623-38AA0

$4.67

6

BULB (12V,21/5W) This part replaces 09471-12083.

09471-12128

$6.08

7

BRACKET This part replaces 35616-41FA1.

35616-41FA3

$68.43

8

CUSHION (6.5X14X6) This part replaces 09320-06016.

09320-06027

$2.12

9

NUT

08310-0010B

$2.95

10

COVER, FRONT TURNSIGNAL This part replaces 35641-41F01.

35641-41F02

$101.80

11

SCREW (5X8)

09139-05042

$2.70

12

NUT

09159-05019

$6.44

13

BOLT

07130-0812B

$2.68

14

WASHER

09160-05048

$1.76

15

LAMP ASSY,RR TU This part replaces 35603-38AC1.

35603-38AC2

$86.12

16

LAMP ASSY,RR TU | Includes Item(s) 17 - 20 This part replaces 35604-38AC1.

35604-38AC2

$74.69

17

LENS | FOR RH

35630-38AE1

$29.21

18

LENS | FOR LH

35610-38AE1

$28.79

19

SCREW

35623-38AA0

$4.67

20

BULB (12V21W)

09471-12045

$2.95

21

NUT

08316-1010B

$2.65

22

RELAY ASSY,TURNSIGNAL LAMP This part replaces 38610-03F00.

38610-03F01

$81.99
