Suzuki VL800 (2009) REAR FENDER (VL800CK7) Diagram

FENDER, REAR (GRAY) | Includes Item(s) 2 - 4

63110-41FG0-YHG

Unavailable

TAPE, RH

68175-41F20-EAY

Unavailable

TAPE, LH

68176-41F20-EAY

Unavailable

.EMBLEM,"SUZUKI" (SILVER) This part replaces 68271-34A00-YES.

68271-34A01-YES

$6.85

CUSHION

47191-24F00

$5.17

WASHER

09160-15002

$1.91

BOLT

63161-41F00

$9.40

CUSHION, PILLION SEAT

09320-15008

$3.89

NUT This part replaces 08316-10083.

08316-1008B

$2.66

CUSHION, BRACE

09321-10007

$2.71
