Suzuki VL1500 (2009) HANDLE LEVER (MODEL K7/K8/K9) Diagram

#

Description

Price

1

GRIP,THROTTLE This part replaces 57110-26D10.

57110-26D11

$39.60

2

LEVER ASSY, BRAKE | Includes Item(s) 3 - 4

57300-48G00

$86.80

3

BOLT, PIVOT

57431-48G00

$10.42

4

NUT

08319-2106A

$1.89

5

SWITCH ASSY,FR BRAKE | Includes Item(s) 6 This part replaces 57460-17C11.

57460-14J02

$35.21

6

SCREW

57465-17C00

$2.37

7

GRIP,L This part replaces 57210-26D00.

57210-26D01

$27.67

8

LEVER ASSY, CLUTCH | Includes Item(s) 9 - 10

57500-10F10

$67.00

9

BOLT, PIVOT

57431-48G00

$10.42

10

NUT

08319-2106A

$1.89

11

SWITCH ASSY, CLUTCH | MODEL K7/K8

57560-10F00

$21.58

11

SWITCH ASSY, CLUTCH | MODEL K9

57560-10F10

$32.52
